1108-07
[return to Table of Contents]
SAFETY LATCHES
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-1633 LATCH
MODEL 1108-1633-1 LATCH w/ WELDED SHAFT
I.D. Ø17/32" 6-5/16"
*These parts are SOLD SEPARATELY.

O.D. Ø1/2"
MODEL
1108-1633
O.D. Ø1" LATCH*
MODEL 1108-1633-1
2-7/8" LATCH w/ SHAFT*
I.D. 3/8"
(one end welded to latch)
1108
1633 SUB FOR: PENZ 25-15-2 1633-1 SUB FOR: PENZ 25-15-1
FITS: PENZ 90-07, 90-11, 90-12, 90-16, 90-17 & 90-18 TWISTLOCKS
3/4" MATERIAL: FAB. STEEL FINISH: PRIMER
3/4" 29/32"
1633 WEIGHT: 0.3 LBS 1633-1 WEIGHT: 0.6 LBS

MODEL 1108-1642-17
1-1/16" LATCH BRACKET
MODEL 1108-1642-17-KIT
1-1/8" 1-1/8" LATCH BRACKET KIT
3-9/16" 1-1/16"
3/8" 3/8" Includes: 1110-4542 Nut
& 1110-4637-G5 Bolt
7/16"
2-5/16"
1-3/16" Fits older Buffers 1642 Pinlocks
3-15/16" w/ open Latch area
5-3/4" 13/16"

FITS: BUFFERS 1103-1642 PINLOCK Install w/ 1 ea. 1110-4637-G5
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED Latch Bolt & 1110-4542 Hex Nut
BRACKET WEIGHT: 1.33 LBS KIT WEIGHT: 1.37 LBS to hold the Latch Bracket in place.

MODEL 1108-1642-18 MODEL 1108-1665
Non-handed 1/4" 1/2"

I.D. Ø3/8" x 2 HOLES
I.D. Ø13/32" x 2 HOLES
1-1/4"
31/32"
3/4" 4" 1-7/8"
2-3/8"
7"
5-13/32" 5/16"
SUB FOR: PENZ 25-29
FITS: BUFFERS 1103-1642 PINLOCK FITS: SCHULZ FB44HL PINLOCK
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: PRIMER
WEIGHT: 0.45 LBS WEIGHT: 0.7 LBS
