SAFETY LATCHES & TABS
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-2848 MODEL 1108-2851
BRACKET TAB/CLIP LATCH ASSEMBLY

1-1/8" 1"

1-1/8"
1/4" 1-1/2"

1108-2851 LATCH ASSEMBLY includes:
I.D. Ø3/8" 1108-1350 Latch (Penz 25-11)
1108-1468 Latch Bracket (Penz 25-27-A) 1108
SUB FOR: PENZ 25-19 1110-4634 Split Roll Pin
WORKS WITH: LATCH UA-0814N
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED Kit components are ALSO sold separately.
WEIGHT: 0.145 LBS

7/8"
MODEL 1108-2870 1-1/4" 1/4"
9/16"
15/16" 4-3/16"
I.D. Ø3/8"
1-5/16" x 2 HOLES
1-1/4"
2"
1/2" 1"
@45º
2-9/16" 7/16"
3-7/16" 1-5/8" 1-15/16" 5/8"
5/16" 4-5/8"
SUB FOR: PENZ 25-34 SUB FOR: PENZ 25-27 FITS: BUFFERS
FITS: PENZ 90-42-XX & 90-42LP-XX “HI-LOW” PINLOCKS 1103-1624 & SCHULZ FB88HL PINLOCKS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL WEIGHT: 0.5 LBS
WEIGHT: 0.28 LBS LATCH & BRACKET FINISH: ZINC-PLATED

MODEL 1108-2922
LATCH TAB

1-1/4" I.D. Ø3/8"

7/8"
1/4" 1-1/4"

1"

MATERIAL: FAB. STEEL FINISH: PRIMER
WEIGHT: 0.14 LBS
