Page 240 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1108-04
[return to Table of Contents]
SAFETY LATCHES

for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-1268
1/4" for West Lake ML-90 Pinlocks

2" 4-1/4"
1/2"
I.D. Ø3/8" x 2 HOLES

1-3/8"
1/2"
1108
1-13/16" SUB FOR: PENZ 25-58, WEST LAKE 1304
4-7/8" FITS: WEST LAKE ML-90-2/3 PINLOCKS
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
6-1/4" WEIGHT: 0.47 LBS

3/16" MODEL 1108-1271-L
MODEL 1108-1271-R
15/16" for West Lake ML-85 Twistlocks

I.D. Ø7/16"
I.D. Ø5/16"
MODEL 1108-1271-L
1-7/16" MODEL 1108-1271-R
7/16"
SUB FOR: WEST LAKE 1223
FITS: WEST LAKE ML-85-2/3, ML-85-4/5 TWISTLOCKS
1-9/16"
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
5-3/4" WEIGHT: 0.3 LBS

MODEL 1108-1345

3/4" 1/2"

5-13/16"
I.D. Ø7/16"
x 2 HOLES

1-7/8"
1-3/16" SUB FOR: PENZ 25-06
FITS: BUFFERS 1101-3606-L/R, 1101-3606-LP-L/R,
1101-3706-L/R, 1101-3707-L/R; SCHULZ F33, F33NS;
PENZ 90-05, 90-05/A & 90-06 TWISTLOCKS
1-1/2" MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 0.84 LBS

904-696-0010

E-mail: sales@buffersusa.com
1108-4 10/25/23
