Page 237 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1108-01
[return to Table of Contents]
SAFETY LATCHES
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

15/16" LATCH KIT MODEL 1108-1129-18
3/4" 5/16"
1108-1129-18-1 Kit components are ALSO sold separately:
Latch Guide
LATCH GUIDE MODEL 1108-1129-18-1
LATCH PIN MODEL 1108-1129-18-2
2-5/16"
3-3/4" 1" 1108-1129-18-2
Gravity Latch Pin
(supplied w/ 1110-4526-SS
Split Roll Pin inserted)
O.D. 3/8" SHOWN SHOWN Install Latch Pin into
UNLOCKED LOCKED Latch Guide BEFORE 1108
welding to Twistlock.
FITS: BUFFERS 1101-1129 & 1101-3539 SCREWDOWN TWISTLOCKS 1129-18 KIT WEIGHT: 0.25 LB
1129-18-1 MATERIAL: CAST STEEL 1129-18-1 FINISH: PRIMER 1129-18-1 WEIGHT: 0.15 LB
1129-18-2 MATERIAL: STAINLESS STEEL 1129-18-2 FINISH: SELF-COLOR 1129-18-2 WEIGHT: 0.1 LB

MODEL 1108-1130-18-LH
MODEL 1108-1130-18-RH

1/4"

I.D. Ø5/16" I.D. 3/8"
1108-1130-18-LH 1108-1130-18-RH
1-13/16"

4" FITS: DURALOC 1101-1130 TWISTLOCK
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.26 LB

MODEL 1108-1130SA-18

1/4"
I.D. Ø3/8"

1"

2-1/2"

FITS: DURALOC 1101-1130SA TWISTLOCK
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.1 LB

904-696-0010
E-mail: sales@buffersusa.com
1108-1 1/23/23
