1107-39
[return to Table of Contents]
HANDLE EXTENSIONS
for TWISTLOCKS w/ LATCHES
CHASSIS | FLATBED TRAILERS

Extension
1107-6941 HANDLE 1" Length
EXTENSION BRACKET 25 MM
for Twistlocks w/ Latches 3/8"
10 MM
5"
1107 1101-3733-R TWISTLOCK w/ 6941 HUB 127 MM

3"
76 MM
4"
102 MM
MODEL 1107-6941-76-KIT 5"
WEIGHT: 2.32 LBS / 1.05 Kg 127 MM
MODEL 1107-6941-102-KIT 6"
WEIGHT: 2.42 LBS / 1.1 Kg
WEIGHT: 2.42 LBS / 1.1 Kg 152 MM
MODEL 1107-6941-127-KIT
FITS BUFFERS 3500, 3600 & 3700 WEIGHT: 2.5 LBS / 1.13 Kg
SERIES TWISTLOCKS w/ LATCHES
MODEL 1107-6941-152-KIT
REPLACEMENT PARTS WEIGHT: 2.62 LBS / 1.19 Kg

ITEM # PART # NAME / DESCRIPTION WEIGHT
1 MODEL 1107-6941 EXT. BRACKET for Twistlocks w/ Latches, Zinc-plated 1.33 LBS / 0.61 Kg
2 MODEL 1107-6943 HANDLE for 3" (76 mm) extension, Zinc-plated 0.74 LB / 0.34 Kg
3 MODEL 1107-6944 HANDLE for 4" (102 mm) extension, Zinc-plated 0.83 LB / 0.38 Kg
4 MODEL 1107-6945 HANDLE for 5" (127 mm) extension, Zinc-plated 0.91 LB / 0.42 Kg
5 MODEL 1107-6946 HANDLE for 6" (152 mm) extension, Zinc-plated 1 LB / 0.45 Kg
6 MODEL 1110-4510-G8 HEX BOLT, 1/2", Grade 8, Zinc-plated 0.17 LB / 0.08 Kg
7 MODEL 1110-4511-J HEX JAM NUT, 1/2" w/ Nylon Insert, Zinc-plated 0.05 LB / 0.02 Kg
8 MODEL 1110-4631-G5 HEX BOLT, 5/16", Grade 5, Zinc-plated 0.04 LB / 0.02 Kg
9 MODEL 1110-4632 HEX NUT, 5/16" w/ Nylon Insert, Zinc-plated 0.01 LB / 0.01 Kg

7 1
6

9
8 4-9/16" 5-1/2"
3-9/16" 116 MM 141 MM
2-9/16" 91 MM
2 65 MM 3 4 5

for 3" (76 mm) extension for 4" (102 mm) extension for 5" (127 mm) extension for 6" (152 mm) extension

904-696-0010
E-mail: sales@buffersusa.com
1107-38 11/29/23
