1107-32
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS

SPECIAL ORDER ONLY MODEL 1107-6214-4 MODEL 1107-6429-KIT
TWISTLOCK HANDLE TWISTLOCK HANDLE ASSEMBLY
Inlcudes all loose parts shown:

HEX NUT
w/ NYLON INSERT
COLLAR

6-3/16"
1107 I.D. 9/32" 157 MM
Ø7 MM
HANDLE SHAFT
O.D. 13/16"
Ø20 MM
O.D. 5/8"
Ø16 MM
4"
101.6 MM
SUB FOR: HOLLAND REPAIR KIT GL726-099-197
FITS: HOLLAND GL 726-099-195-GF (Non-Retractable)
SUB FOR: ROCK ISLAND 12018A4002-P & GL726-099-196 (Retractable) TWISTLOCKS
FITS: BUFFERS 3701-6214-G WORKS WITH: BUFFERS 1105-6428-INNER PIN ASSEMBLY
NON-RETRACTABLE TWISTLOCK MATERIAL: FAB. STEEL MATERIAL: HOT-ROLLED STEEL FINISH: PRIMER
FINISH: HOT-DIP GALVANIZED WEIGHT: 0.35 LB WEIGHT: 2.3 LBS

MODEL 1107-6940 MODEL 1107-7342
TWISTLOCK HANDLE TWISTLOCK HANDLE
Bent 39º Fork type

141º
5" 1-1/2"

5"
O.D.
1-1/2" I.D. Ø3/4" Ø3/4"
O.D. Ø1/2"

3/4" 1-1/2"
2-1/4" 9"
FOR 5/8" DIAMETER HANDLE, SEE MODEL 1107-1536
FOR 3/4" DIAMETER HANDLE, SEE MODEL 1107-1562 11-3/4"

SUB FOR: PENZ 20-61 SUB FOR: PENZ 20-17
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.55 LBS WEIGHT: 1.82 LBS

904-696-0010
E-mail: sales@buffersusa.com
1107-32 11/7/22
