1107-30
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1107-3533-4-OS127 MODEL 1107-3600-4
TWISTLOCK HANDLE T-HANDLE for 1101-3600-HA
Flatbed Use Only – Extended series Twistlocks
I.D. Down 5" w/ Latch Arm
Ø1-9/16"

I.D. I.D. Ø1-11/16"
Ø1/2" 2-15/16"
1107

O.D.
Ø5/8"
7"
5"
I.D. Ø1/2"
O.D.
Ø5/8" 1-1/4"

5-1/16" FITS: BUFFERS 1101-3600-HA SERIES
HEIGHT-ADJUSTABLE FLATBED TWISTLOCKS
FITS: BUFFERS 1101-3533-R, 1101-3590-R & 1101-3733-R WORKS WITH: BUFFERS 1105-3600-2 PIN & 1105-3600-INNER
FLATBED TWISTLOCKS WORKS WITH: BUFFERS PIN ASSEMBLY; 1107-3600-4-9 (older style/round) &
1105-3533-2 PIN, 1105-3533-INNER PIN ASSEMBLY 1107-3600-4-9-SQ (newer style/sq.) HANDLE EXTENSION TUBES
& 1108-3633-18 LATCH MATERIAL: FAB. STEEL MATERIAL: CAST STEEL FINISH: PRIMER
FINISH: ZINC-PLATED WEIGHT: 2.65 LBS WEIGHT: 1.35 LBS / 0.61 Kg

MODEL 1107-3600-4-SQ MODEL 1107-3600-4-9-SQ
2-7/8"
T-HANDLE w/ Square Upper 72.5 MM HANDLE EXTENSION TUBE
for 1101-3600-HA series Twistlocks for 1101-3600-HA series Twistlocks
(newer style w/ square latch) (newer style w/
square latch)
2-7/8"
72.5 MM
2-1/4"
57 MM
I.D. 1/2"
Ø13 MM
2-1/4"
57 MM 14-3/16"
360 MM
9-13/16"
248.5 MM
I.D. 1/2"
Ø13 MM
O.D. 5/8"
Ø19 MM
I.D. 1/2"
Ø13 MM
5-1/2"
139.7 MM
FITS: BUFFERS 1101-3600-HA SERIES HEIGHT-ADJUSTABLE
FITS: BUFFERS 1101-3600-HA SERIES HEIGHT-ADJUSTABLE FLATBED TWISTLOCKS (newer style: square/latched)
FLATBED TWISTLOCKS (newer style: square/latched) WORKS WITH: BUFFERS 1107-3600-4 HANDLE
MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 5.4 LBS / 2.45 Kg WEIGHT: 7.2 LBS / 3.27 Kg

904-696-0010
E-mail: sales@buffersusa.com
1107-30 11/7/22
