1107-29
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1107-3529-4 MODEL 1107-3532-4-OS35

SPECIAL ORDER MODEL 1107-3529-4-HDG TWISTLOCK HANDLE
Offset/extended
I.D. O.D. Ø1-13/16" TWISTLOCK HANDLE down 35 mm
Ø1-5/16" Screwdown Type Only
I.D. Ø1-1/4"
O.D. 5/8"
Ø16 MM
1-1/8" I.D. Ø1/2"
O.D. 2-1/16"
Ø52 MM
O.D. Ø5/8"
I.D. 1-1/2" 1107
Ø39 MM
5"
9/16" I.D. 1/2" 1-3/8"
FITS: BUFFERS 1101-3529-RS/NRS, 1102-3539-RS/NRS, 14 MM Ø13 MM 35 MM
1101-3629-RS/NRS, 1101-3729-RS/NRS & 1101-3829-NRS
TWISTLOCKS WORKS WITH: BUFFERS 1105-3529-INNER,
1105-3539-INNER, 1105-3629-INNER & 3829-INNER PIN 1-15/16"
ASSEMBLIES, 1110-4531-G5 HEX BOLT & 1110-4511 HEX NUT 2-1/2" 49 MM
MATERIAL: STEEL FINISH: ZINC-PLATED WEIGHT: 0.7 LB 63 MM
Extended Hub lengths available 4"
for Flatbed applications: 101.5 MM
3-7/8"
2-1/2" 70 MM FITS: BUFFERS 1101-3532 RETRACTABLE FLATBED
35 MM TWISTLOCK WORKS WITH: BUFFERS
1105-3532-2 PIN & 1105-3532-INNER PIN ASSEMBLY
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.75 LB
1107-3529-4-OS35 1107-3529-4-OS70
WEIGHT: 1.14 LBS WEIGHT: 1.58 LBS

MODEL 1107-3532-4-OS70 MODEL 1107-3533-4-OS70
TWISTLOCK HANDLE TWISTLOCK HANDLE
Offset/extended Offset 70 mm
down 70 mm

O.D. 5/8"
Ø16 MM
O.D. 2-1/16"
Ø52 MM
I.D. Ø1-9/16"
I.D. 1-1/2" / Ø39 MM
I.D. Ø1/2"
9/16" 1-3/32"
14 MM I.D. 1/2" 3-5/16"
2-3/4"
Ø13 MM 70 MM 84 MM
3-7/8" 2-3/4"
98 MM
4"
101.5 MM 6-1/2"
FITS: BUFFERS 1101-3532 RETRACTABLE FLATBED FITS: BUFFERS 1101-3533-R, 1101-3590-R & 1101-3733-R
TWISTLOCK WORKS WITH: BUFFERS FLATBED TWISTLOCKS WORKS WITH: BUFFERS
1105-3532-2 PIN & 1105-3532-INNER PIN ASSEMBLY 1105-3533-2 PIN, 1105-3533-INNER PIN ASSEMBLY
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED & 1108-3633-18 LATCH MATERIAL: FAB. STEEL
WEIGHT: 1.05 LB FINISH: ZINC-PLATED WEIGHT: 1.04 LBS
