TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-3269-R
2-9/16" 7"
65 MM 178 MM MODEL 1102-3269-L

2-3/16"
55.2 MM
90º 1102

MODEL 1102-3269-R MODEL 1102-3269-L
1-3/16" for Front Roadside for Front Curbside
30 MM & Rear Curbside & Rear Roadside

1-5/16"
6-7/16" 33.5 MM
164 MM
3-3/16" O.D. 3-3/16" 9/16"
3-15/16" 80 MM Ø81 MM 14 MM
100.5 MM
O.D. 3/4"
Ø19 MM
1102-3269-R SHOWN DIMENSIONED
MODEL 1102-3269-L IS MIRROR OPPOSITE.
FINISH: WELDABLE PRIMER
EXPLODED VIEW
WEIGHT: 9.26 LBS / 4.2 Kg

1110-4549
DETENT BALL 1105-1257-2
(2 pcs.) PIN
. Same as 1102-1259 Twistlocks except for
1110-4550
DETENT SPRING Handle to Pin c/c
. Standard locking clearance
. Dual Grease Fittings
. Weld chamfer on Housing
1110-4503
GREASE FITTING . Designed to hang straight for welding
(2 pcs.)
1109-1257-1
HOUSING

1110-4511
LOCK NUT
1110-4769-G8
HEX BOLT PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-3269-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.

904-696-0010
