1102-16
[return to Table of Contents]
TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-3262-R
MODEL 1102-3262-L

2-3/8"
60.5 MM
90º

2-3/4"
7-1/2"
1102 70 MM 190.5 MM

MODEL 1102-3262-R
for Front Roadside
2" & Rear Curbside
50.8 MM
MODEL 1102-3262-L
for Front Curbside
& Rear Roadside

1-5/16"
33.5 MM

O.D. 3-3/16"
3-3/16" 9/16"
3-13/16" 80 MM Ø81 MM 14 MM
97 MM
O.D. 3/4"
Ø19 MM
FINISH: PRIMER
EXPLODED VIEW
WEIGHT: 10.27 LBS / 4.66 Kg

1110-4549
DETENT BALL 1105-3557-2
(2 pcs.) PIN .
1110-4550 . Standard locking clearance
.
DETENT SPRING Dual Grease Fittings
. Weld chamfer on Housing
Designed to hang straight for welding
1110-4503 . High Cone design
GREASE FITTING 1109-1257-1
(2 pcs.) HOUSING

1110-4511
LOCK NUT
1110-4524-G5
HEX BOLT
PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-3260-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.

904-696-0010
E-mail: sales@buffersusa.com
1102-16 12/3/20
