Page 130 - Buffers USA 2024 Lashing Gear & Marine Hardware Catalog FlipBook

5006-20

CONTAINER HEIGHT
EXTENDERS

SPECIAL ORDER ONLY MODEL 5006-BUI-6-TL
SPECIAL ORDER ONLY MODEL 5006-BUI-6-TR
SPECIAL ORDER ONLY MODEL 5006-BUI-9.5
MODEL 5006-BUI-12

40' 40'

MODEL 5006-BUI-6-TL MODEL 5006-BUI-12
MODEL 5006-BUI-6-TR

20' x 8' 20' x 8'6" 20' x 8'6" 20' x 9'6"

5006-BUI-6-TL
5006 5006-BUI-6-TR 5006-BUI-12

WEIGHT: 17.2 Kg / 38 LBS
Model 5006-BUI-6-TL/-TR for 6" height difference.
Supplied with integral Twistlock. WEIGHT: 24 Kg / 53 LBS
Model 5006-BUI-12 for 12" height difference.
Must be attached with a Ship Twistlock to 8'6" Container
MODEL 5006-BUI-9.5 to achieve 12" height above 8'6" Container.

6201-1369-TL
20' ISO SPREADER
SPREADER
6201-1371-BL
5006-BUI-9.5 5006-BUI-9.5

WEIGHT: 21.3 Kg / 47 LBS
Model 5006-BUI-9.5 for 9-1/2" height difference.
ISO Apertures are placed in line.
Fits on Chassis Twistlocks and allows
loading and locking of ISO Lift Spreader.

MIN. B.S. COMPRESSION: 100 M. TON
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED (HDG)

904-696-0010
E-mail: sales@buffersusa.com
5006-20 10/31/23
