P. 117
5006-07
STACKING CONES
®
BOTTOM TYPE, DOUBLE, LONGITUDINAL
MODEL 5006-C9B-279B
GIVES 3" SPACE BETWEEN
ENDS OF 20' CONTAINERS
65 MM 279 MM 50 MM
2-9/16" 11" 2"
30 MM
66 MM 1-3/16"
2-19/32"
12 MM
15/32"
22 MM
7/8"
5006
130 MM
5-1/8"
95 MM
3-3/4"
MIN. B.L. SHEAR: 42 M. TON
MIN. B.L. TENSION: 36 M. TON
MATERIAL: FORGED STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
WEIGHT: 7.0 Kg / 15.4 LBS
®
904-696-0010 FAX: 904-696-0019
E-mail: sales@buffersusa.com
5006-7 7/6/18
