1210-11
[return to Table of Contents]
TUNNEL & TUNNEL RAILS

ISO CONTAINERS

17-3/16" SPECIAL ORDER ONLY MODEL 1210-2626
436.4 MM
1-1/2" 14-1/8" 1-1/2" CONTAINER FORK TUNNEL
38.8 MM 358.8 MM 38.8 MM

5" 3/16"
127 MM 4.2 MM
1210

83-5/8"
1" 2,124 MM 1"
25.4 MM 25.4 MM

I.D. 3/4" 9-3/8"
Ø19 MM 31-5/8" 238.1 MM
x 4 HOLES 803 MM
53-1/2"
76-9/16" 1,359 MM
1,945 MM
85-5/8"
2,175 MM
1" FITS: 20' x 96" ISO
25.4 MM MATERIAL: STRUCTURAL STEEL
1/2" FINISH: PRIMER
12.7 MM
WEIGHT: 101.5 LBS / 46 Kg

MODEL 1210-2750 MODEL 1210-7158
TUNNEL RAIL TUNNEL RAIL

3-3/4"
4-3/16" 94.5 MM
106.5 MM

3/16"
3/16" 2-3/4"
2-3/4" 4.5 MM 70 MM 4.5 MM
70 MM
4-3/16" 4-9/16"
106.5 MM 115.7 MM

2-5/16" 2-5/16" 120°
58 MM 58 MM
2-3/4"
70 MM 2-3/4"
70 MM

SUB FOR: CIMC D33-02-26 SUB FOR: CIMC D33-02-01
FITS: 40' x 96" ISO LENGTH: 10' / 3,048 MM FITS: 40' x 96" ISO LENGTH: 9' 6" / 2,892 MM
MATERIAL: CORTEN STEEL FINISH: GRAY PRIMER MATERIAL: CORTEN STEEL FINISH: GRAY PRIMER
WEIGHT: 47 LBS / 21.3 Kg WEIGHT: 44.6 LBS / 20.2 Kg

904-696-0010
E-mail: sales@buffersusa.com
1210-9 3/2/23
