2903-01
[return to Table of Contents]
WEB WINCHES

ISO FLATRACK, FLATBED & AUTO TRAILERS

MODEL 2903-2691 MODEL 2903-2692 MODEL 2903-2693
WELD-ON SPECIAL ORDER ONLY WELD-ON WELD-ON
Standard Storage Side Mount

8" 8"
PAINTED BLACK 202.5 MM PAINTED BLACK 202.5 MM PAINTED BLACK 8"
202.5 MM
5-1/2" 6-3/16" 3-15/16"
140 MM 157 MM 100 MM

3-9/16" 4-7/8" 3-9/16" 4-7/8" 4-3/8" 4-7/8"
90 MM 124 MM 90 MM 124 MM 110 MM 124 MM
SUB FOR: ANCRA 43563-10, SUB FOR: SUB FOR: ANCRA 43579-20,
KINEDYNE 1820, MULTIPRENS 1160 ANCRA 43573-10, KINEDYNE 1820S KINEDYNE 7820, MULTIPRENS 1165
WEIGHT: 8.3 LBS / 3.8 Kg WEIGHT: 8.9 LBS / 4 Kg WEIGHT: 7.5 LBS / 3.4 Kg
MODEL 2903-2694 MODEL 2903-2695 MODEL 2903-2696
BOLT-ON BOLT-ON BOLT-ON
Standard Storage Side Mount

8" 8"
PAINTED BLACK 202.5 MM PAINTED BLACK 202.5 MM PAINTED BLACK 8" 2903
202.5 MM

3-15/16"
5-1/2" 6-3/16" 100 MM
140 MM 157 MM
3-9/16" 4-7/8" 3-9/16" 4-7/8" 4-3/8" 4-7/8"
90 MM 124 MM 90 MM 124 MM 110 MM 124 MM
SUB FOR: ANCRA 43564-14, SUB FOR: ANCRA 43564-16,
KINEDYNE 1820 P2, MULTIPRENS 1660 SUB FOR: ANCRA 43564-12 KINEDYNE 7820 P2, MULTIPRENS 1665
WEIGHT: 9 LBS / 4.1 Kg WEIGHT: 9.95 LBS / 4.51 Kg WEIGHT: 9.3 LBS / 4.2 Kg
MODEL 2903-2697 MODEL 2903-2698 MODEL 2903-2699
SLIDER SLIDER SLIDER
Standard Storage Deep Storage

8" 8" 8"
PAINTED BLACK 202.5 MM PAINTED BLACK 202.5 MM PAINTED BLACK 202.5 MM

5-1/2"
140 MM 6-7/8" 7-1/2"
175 MM 190 MM
3-15/16" 4-7/8"
100 MM 124 MM 3-15/16" 4-7/8" 3-15/16"
100 MM 124 MM 100 MM 4-7/8"
124 MM
SUB FOR: ANCRA 43565-15, SUB FOR: ANCRA 43565-12,
KINEDYNE 3820, MULTIPRENS 1760 WEIGHT: 11 LBS / 5 Kg KINEDYNE 5820, MULTIPRENS 1765
WEIGHT: 8.2 LBS / 3.7 Kg WEIGHT: 10.6 LBS / 4.8 Kg

NOTE: FOR LOAD SECURING ONLY, NOT FOR LIFTING. WORKING LOAD LIMIT (WLL): 5,000 LBS / 2,267 Kg
ALL WINCH AND STRAP ASSEMBLIES SHOULD BE BREAK STRENGTH (BS): 15,000 LBS / 6,800 Kg
INSPECTED FOR FRAYS, CUTS, OR DAMAGED
HARDWARE BEFORE AND AFTER USING. DESIGNED TO MEET OR EXCEED WSTDA T-3 STANDARD.

904-696-0010
E-mail: sales@buffersusa.com
2903-1 3/6/23
