D-RINGS w/ STRAPS

ISO FLATRACK, FLATBED & AUTO TRAILERS

A BENT-TYPE D-RINGS
50° NOTE: D-Ring strength for tie-down
C purposes only. NOT FOR LIFTING.
FINISH: B
SC – SELF-COLOR G E
HDG – HOT-DIP GALVANIZED D F
PR – PRIMER
D-RING DIMENSIONS STRAP DIMENSIONS
MODEL DESC. FINISH WEIGHT SWL MBS A B C D E F G
3.54 LBS
2902-7614-1-HDG D-RING HDG 1.61 Kg 15,000 LBS 45,000 LBS 5" 5-1/2" 1" 2-9/16" 1-11/16" 2-7/32" 7/16"
1.20 LBS 6,803 Kg 20,411 Kg 127 MM 140 MM 25.4 MM 65 MM 43 MM 56 MM 11 MM
2902-1578-2-HDG STRAP HDG
0.54 Kg
3.64 LBS
2902-1756-1-HDG D-RING HDG
1.65 Kg
2902-1756-1-SC D-RING SC 3.69 LBS
1.67 Kg 15,667 LBS 47,000 LBS 5" 6" 1" 2-9/16" 1-11/16" 2-7/32" 7/16"
1.20 LBS 7,106 Kg 21,318 Kg 127 MM 152 MM 25.4 MM 65 MM 43 MM 56 MM 11 MM
2902-1578-2-HDG STRAP HDG 0.54 Kg
1.20 LBS
2902-1578-2-SC STRAP SC
0.54 Kg

MARINE-TYPE D-RINGS
A C NOTE: D-Ring strength for tie-down
purposes only. NOT FOR LIFTING.
B 2902
FINISH: G E
SC – SELF-COLOR
HDG – HOT-DIP GALVANIZED D F
PR – PRIMER
D-RING DIMENSIONS STRAP DIMENSIONS
MODEL DESC. FINISH WEIGHT SWL MBS A B C D E F G
0.75 LBS
2902-1160-1-SC D-RING SC 0.34 Kg
0.50 LBS 907 Kg 2,722 Kg 4-3/4" 2-15/16" 9/16" 3-7/16" 1" 1-1/4" 1/4"
2902-1160-2-HDG STRAP HDG
0.23 Kg 2,000 LBS 6,000 LBS 120 MM 74 MM 14 MM 87 MM 25 MM 32.5 MM 7.1 MM
0.50 LBS
2902-1160-2-SC STRAP SC
0.23 Kg
5.70 LBS
5012-1854-1-HDG D-RING HDG
2.59 Kg 20.5 M.TON 41 M.TON 8-7/8" 5-7/16" 1" 4-15/16" 1-13/16" 2-11/16" 1/2"
2.92 LBS 45,195 LBS 90,390 LBS 225 MM 138 MM 25.4 MM 126 MM 45.8 MM 68.7 MM 12 MM
5012-1854-2-HDG STRAP HDG
1.32 Kg
5.70 LBS
3701-2526-1-PR D-RING PR
2.58 Kg
5.67 LBS
3701-2526-1-SC D-RING SC
2.57 Kg 25 M.TON 50 M.TON 8-3/4" 5-11/16" 1" 4-1/2" 2" 2-3/8" 9/16"
55,115 LBS 110,230 LBS 222 MM 143.8 MM 25.4 MM 108 MM 50.8 MM 60.3 MM 15 MM
2.77 LBS
3701-2526-2-PR STRAP PR 1.26 Kg
2.77 LBS
3701-2526-2-SC STRAP SC
1.26 Kg
7.75 LBS
5012-7092-1-PR D-RING PR
3.52 Kg
7.93 LBS
5012-7092-1-HDG D-RING HDG
3.60 Kg 25 M.TON 50 M.TON 9-7/16" 5-15/16" 1-1/4" 5-1/2" 2" 2-7/8" 9/16"
3.32 LBS 55,115 LBS 110,230 LBS 240 MM 151 MM 32 MM 140 MM 50 MM 73 MM 14 MM
5012-7092-2-PR STRAP PR 1.50 Kg
3.05 LBS
5012-7092-2-HDG STRAP HDG 1.38 Kg
