2901-02
               [return to Table of Contents]
                                                                  CHAIN ASSEMBLIES
                                                                             CLEVIS GRAB HOOKS
                                                ISO FLATRACKS & TRAILERS: AUTO / FLATBED






                                                             CLEVIS GRAB HOOKS
                                                            MBS is:
                                                            3 x WLL for GRADE 43
                                                            4 x WLL for GRADE 70 & 80




                                     FOR CHAIN                               WORKING LOAD
                    MODEL            DIAMETER        GRADE          FINISH     LIMIT (WLL)  WEIGHT (per item)
                    2901-5/16GHGR70     5/16"   GRADE 70 TRANSPORT  YELLOW ZINC  4,700 LBS  0.75 LBS / 0.34 Kg
                    2901-3/8GHGR43      3/8"    GRADE 43 HIGH-TEST  SELF-COLOR  5,400 LBS  1.15 LBS / 0.52 Kg
                    2901-3/8GHGR70      3/8"    GRADE 70 TRANSPORT  YELLOW ZINC  6,600 LBS  1.1 LBS / 0.5 Kg
                    2901-3/8GHGR80-CC   3/8"    GRADE 80 CRADLE   PAINTED       7,100 LBS  1.65 LBS / 0.75 Kg
                    2901-1/2GHGR70      1/2"    GRADE 70 TRANSPORT  YELLOW ZINC  11,300 LBS  2.4 LBS / 1.09 Kg
                    2901-1/2GHGR80-CC   1/2"    GRADE 80 CRADLE   PAINTED       12,000 LBS  3.3 LBS / 1.5 Kg
                    2901-5/8GHGR43      5/8"    GRADE 43 HIGH-TEST  SELF-COLOR  13,000 LBS  4.2 LBS / 1.9 Kg
     2901           2901-5/8GHGR80      5/8"    GRADE 80          ZINC-PLATED   18,100 LBS  5.7 LBS / 2.58 Kg













































                                                                                            904-696-0010
                                                                                 E-mail: sales@buffersusa.com
                                                          2901-2                                            11/12/20
