1107-09
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1107-1386 MODEL 1107-1387
TWISTLOCK HANDLE TWISTLOCK HANDLE

5/8"
4-1/4"
I.D. 1107
Ø1/4"
47º
6" 5/8"
O.D. Ø1" 5"

1-1/4"

7-3/4"
SUB FOR: PENZ 20-06 SUB FOR: PENZ 20-16 FOR USE ON: STRICK CHASSIS
FOR USE ON: BUDD & GINDY CHASSIS WORKS WITH: BUFFERS 1105-1351, 1105-1408-L/R,
WORKS WITH: BUFFERS 1105-1510 & PENZ 15-31 PINS 1105-1512-L/R, 1105-2841-L/R & PENZ 15-41, 15-42-XX,
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED 15-43-XX, 15-59-XX PINS MATERIAL: FAB. STEEL
WEIGHT: 2.68 LBS FINISH: PRIMER WEIGHT: 2.1 LBS

MODEL 1107-1388 MODEL 1107-1394
TWISTLOCK HANDLE TWISTLOCK HANDLE

1110-2477 CLEVIS BOLT &
1110-4551-SS COTTER PINS (2 pcs.)
are SOLD SEPARATELY.

I.D. Ø3/16"
1-25/32" O.D.
15º Ø3/4"
5"

I.D. 6"
Ø25/32"
O.D. Ø7/8"
5-1/2" 1-1/2"

3"
SUB FOR: PENZ 20-36 FOR USE ON: FRUEHAUF &
SUB FOR: PENZ 20-33 MAERSK CHASSIS WORKS WITH: BUFFERS 1105-1389,
FOR USE ON: ALLIED & STRICK CHASSIS 1105-1538, 1105-2476, 1105-2853 & PENZ 15-36-A, 15-51,
WORKS WITH: BUFFERS 1105-1538 & PENZ 15-54 PINS 15-54 & 15-134 PINS paired w/ 1110-2477 CLEVIS BOLT +
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED 1110-4551-SS COTTER PINS (2 pcs.) MATERIAL: FAB. STEEL
WEIGHT: 1.53 LBS FINISH: ZINC-PLATED WEIGHT: 1.5 LBS

904-696-0010
E-mail: sales@buffersusa.com
1107-9 6/4/20
