1107-08
[return to Table of Contents]
HANDLES
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1107-1375-L
I.D.
Ø3/8" MODEL 1107-1375-R
TWISTLOCK HANDLES
1-1/2"
3-1/8"

MODEL 1107-1375-L is shown dimensioned.

1" 10-1/4"
1107
MODEL 1107-1375-L
5-25/32" Rear Roadside / Front Curbside

4-7/16"
3/4"

SUB FOR: PENZ 20-01-XX FOR USE ON: THEURER CHASSIS
WORKS WITH: BUFFERS 1105-1451 & PENZ 15-26 PINS; MODEL 1107-1375-R
BUFFERS 1108-1785-L/R & PENZ 20-25-XX LATCHES
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 3.67 LBS Rear Curbside / Front Roadside

MODEL 1107-1376 MODEL 1107-1377
TWISTLOCK HANDLE PINLOCK HANDLE

SUPPLIED w/
Ø1/4" x 1-1/4"
SPLIT ROLL PIN 3-7/16"
45º
19/32"

7-5/16" 9"
4"

2-1/8"
2-1/8"
3-7/16" 1-3/16"
O.D. Ø5/8"
SUB FOR: PENZ 20-13 SUB FOR: PENZ 20-115
FOR USE ON: BERTOLINI CHASSIS FOR USE ON: STRICK CHASSIS
WORKS WITH: BUFFERS 1105-1453-L/R, 1105-1455-L/R WORKS WITH: BUFFERS 1106-1518-L/R PINS
& 1105-1579-L/R PINS MATERIAL: CAST STEEL MATERIAL: FAB. STEEL FINISH: PRIMER
FINISH: PRIMER WEIGHT: 2.28 LBS WEIGHT: 0.9 LBS

904-696-0010
E-mail: sales@buffersusa.com
1107-8 12/10/20
