1107-06
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1107-1352 Shipped w/ Nut hand-tightened MODEL 1107-1353
TWISTLOCK HANDLE onto end as shown: TWISTLOCK HANDLE
1-9/16"
1107 1-17/32" 5/8"-11 TPI threads
5-3/8"
9-15/32"
I.D. O.D.
Ø1/2" Ø3/4" 2-9/32"
1-1/2"
O.D. Ø3/4"
2-5/8" 9"
SUB FOR: PENZ 20-25 SUB FOR: PENZ 20-76-MOD
WORKS WITH: PENZ 15-47-XX PIN FOR USE ON: HYUNDAI CHASSIS
FOR USE ON: TRAILMOBILE CHASSIS WORKS WITH: BUFFERS 1105-1356-L/R &
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED PENZ 15-96-XX PINS MATERIAL: FAB. STEEL
WEIGHT: 1.85 LBS FINISH: ZINC-PLATED WEIGHT: 2.1 LBS
MODEL 1107-1354 MODEL 1107-1355
TWISTLOCK HANDLE TWISTLOCK HANDLE
1-3/16"
1-5/8"
4-15/32" O.D.
Ø5/8"
7-5/16"
10"
I.D.
Ø13/32"
O.D. Ø3/4"
SUB FOR: PENZ 20-27
FOR USE ON: SEALAND CHASSIS SUB FOR: PENZ 20-34
WORKS WITH: BUFFERS 1105-1458-L/R & FOR USE ON: STRICK CHASSIS
PENZ 15-57-XX PINS MATERIAL: FAB. STEEL MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
FINISH: ZINC-PLATED WEIGHT: 1.3 LBS WEIGHT: 0.88 LBS
904-696-0010
E-mail: sales@buffersusa.com
1107-6 6/4/20
