TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1532
2" for Miller chassis
I.D. 11/16" 50.8 MM
Ø17.4 MM

3-7/8"
1" 98.4 MM
25.4 MM 4-1/2"
114.3 MM
2-1/4"
I.D. 3/4" 5-1/4" 57 MM
Ø19.1 MM 133.4 MM
1105
O.D. 1-3/8"
Ø34.9 MM
SUB FOR: PENZ 15-27 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.5 LBS / 2.04 Kg

MODEL 1105-1533-L
MODEL 1105-1533-R
for Budd chassis
2"
50.8 MM 1105-1533-L 1105-1533-R
3-7/8"
98.4 MM
45º
2-13/16"
71.4 MM 3-3/4" 2-1/4"
95.3 MM 57.2 MM

O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-46-XX WORKS WITH: 1109-1492 RISER BLOCK
15/16" HIGH MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.2 LBS / 1.91 Kg
x 5/8" WIDE SLOT

MODEL 1105-1538
2" for Allied & Strick chassis
50.8 MM

3-7/8"
98.4 MM
3-11/16"
I.D. 15/16" 93.7 MM
5-1/2" Ø23.8 MM 2-1/4"
139.7 MM 57 MM

O.D. 1-7/8"
Ø47.6 MM
SUB FOR: PENZ 15-54 WORKS WITH: BUFFERS 1107-1388 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.6 LBS / 2.99 Kg
