Page 156 - Buffers USA 2024 Chassis Hardware Catalog FlipBook

1105-23
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1458-L
MODEL 1105-1458-R
1-1/4" for SeaLand chassis
31.8 MM 1/16" 1105-1458-L 1105-1458-R
1.5 MM

O.D. 1-11/16" 2-15/16" 4-3/16"
74.7 MM
Ø42 MM 4-15/16" 106.4 MM
125.5 MM
I.D. 15/32" 45º
1105 Ø11.9 MM
2"
I.D. 3/8" 50.8 MM
Ø9.9 MM

8-7/16"
O.D. 1-1/8" 214.4 MM SUB FOR: PENZ 15-57-XX WORKS WITH: BUFFERS 1107-1354 HANDLE
Ø28.6 MM MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.52 LBS / 2.05 Kg

MODEL 1105-1461-L
MODEL 1105-1461-R
for Trailmobile chassis
1-1/4"
31.8 MM 1105-1461-L 1105-1461-R
1/16" 3-3/4"
1.6 MM
95.3 MM
O.D. 2" 27º
Ø50.8 MM 2-13/16"
71.4 MM 2"
50.8 MM
3-11/16"
O.D. 1-1/2" 93.7 MM
Ø38.1 MM
SUB FOR: PENZ 15-45-XX WORKS WITH: BUFFERS 1107-1619 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.63 LBS / 2.1 Kg

MODEL 1105-1462
2"
50.8 MM

3-7/8"
98.4 MM
I.D. 15/16" 3-11/16"
Ø23.8 MM 93.7 MM 2-1/4"
57 MM
5-1/2"
139.7 MM

O.D. 1-3/4"
Ø44.5 MM SUB FOR: PENZ 15-75 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 6.05 LBS / 2.74 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-23 12/5/22
