1105-18
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1359
2" UNDRILLED
50.8 MM for Utility chassis

3-7/8"
98.4 MM
O.D. 1-1/2"
Ø38.1 MM 5/8"
2-1/4"
15.9 MM 57.2 MM
5-3/4"
146.1 MM
1105

O.D. 1-1/4"
Ø31.8 MM SUB FOR: PENZ 15-56
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 4.81 LBS / 2.18 Kg

MODEL 1105-1389
2" 6" PIN for Fruehauf chassis
50.8 MM

3-7/8"
98.4 MM
3-7/8"
I.D. 3/4"
Ø19.5 MM 98.4 MM 2-1/4"
57.2 MM
6"
152.4 MM

O.D. 1-3/4"
Ø44.5 MM
SUB FOR: PENZ 15-36-A WORKS WITH: BUFFERS 1107-1394 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.63 LBS / 3.01 Kg

MODEL 1105-1390
4" PIN for Fruehauf chassis
2"
50.8 MM

3-7/8"
98.4 MM
O.D. 2-1/4" 1/4" 3-1/8" 2-1/4"
Ø57.2 MM 6.4 MM 79.4 MM 4-1/4" 57.2 MM
108 MM
I.D. 3/4"
Ø19.6 MM

O.D. 1-3/4"
Ø44.5 MM SUB FOR: PENZ 15-36-B
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 5.4 LBS / 2.45 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-18 12/5/22
