1101-40
[return to Table of Contents]
TWISTLOCK REPLACEMENT PARTS
FOR DISCONTINUED MODELS
FLATBED TRAILERS

MODEL 1101-3600-HA-KIT IMPORTANT NOTICE
HEIGHT-ADJUSTABLE TWISTLOCK w/ T-HANDLE (no Latch) *Canadian Customers: In order to meet
*
Replaced by 3600-HA-WL-KIT (w/ T-Handle & Latch) Canadian road regulations, a secondary lock is
REQUIRED to ensure the 1101-3600-HA Twistlock
FINISH: PRIMER WEIGHT: 45.6 LBS / 20.68 Kg (older style w/ round handle extension) does not
6" 6" 3" rotate to the unlocked position:
5-1/2" 6-1/4" See table below for Latch retrofit guide:
1101
Twistlock Assembly Components Needed
1105-3600-29-112 12-3/4" to Retrofit Latch Assy.**
Pin Sleeve RETRACTED 9-1/4"
1101-3600-HA-KIT 1108-3600-HA-18-SL Latch
(for handle on round tube)
7" DECK LEVEL EXTENDED POSITION
RETRACTED (locked position) (ready to lock) 1101-3600-HA-9-KIT & 1108-3600-HA-18-SL-SQ-KIT
1101-3600-HA-9-NH-KIT Latch (for handle on sq. tube),
Remove/discard INNER**, 1105-3600-INNER
(w/ 2 handle bolt holes**),
MODEL 1101-3600-HA-9-KIT Round Extension Tube & Pin 1107-3600-4-9-SQ Handle,
Sleeve, Upper Bolt & Nut,
HEIGHT-ADJUSTABLE TWISTLOCK * then fit new components 1110-4510-G8 Hex Bolt &
w/ HANDLE EXTENSION TUBE & T-HANDLE (no Latch) to twistlock*** 1110-4511-J Hex Jam Nut
Replaced by 3600-HA-9-WL-KIT (w/ 9" Square Extension Tube, T-Handle & Latch) ** Only needed for longitudinal latch operation. Can use existing
INNER if transversal latch operation works.
FINISH: PRIMER WEIGHT: 50.15 LBS / 22.75 Kg *** NOTE: Retrofit Installation Guide with detailed, step-by-step
instructions is available; ask your Sales Representative.

COMPONENTS USED ON 1101-3600-HA
TWISTLOCKS (old style w/ round handle extension):
1105-3600-29-91 19-5/8"
Pin Sleeve RETRACTED I.D. Ø1-11/16"
MODEL 1107-3600-4
1110-4594-G8 16-7/8" T-Handle
Upper Hex Bolt 1110-4511 13-7/8"
Lower 7"
1110-4511 Hex Nut
Upper Hex Nut I.D. Ø1/2" 1-1/4"
FINISH: PRIMER
1110-4594-G8 WEIGHT: 1.4 LBS / 0.64 Kg
Lower Hex Bolt RETRACTED DECK LEVEL EXTENDED POSITION

MODEL 1101-3600-HA-9-NH-KIT
HEIGHT-ADJUSTABLE TWISTLOCK * MODEL 1107-3600-4-9
w/ EXTENSION TUBE ONLY (no handle or latch) Handle Extension Tube
Replaced by 3600-HA-9-NH-WL-KIT (w/ 9" Square Extension Tube & Latch – no handle) FINISH: ZINC-PLATED 7-5/8"
WEIGHT: 4.35 LBS / 1.97 Kg
FINISH: PRIMER WEIGHT: 48.6 LBS / 22.04 Kg

MODEL 1105-3600-INNER
1105-3600-29-91 19-5/8" Pin Assembly
Pin Sleeve RETRACTED (older design w/ 1 Handle Bolt Hole)
1110-4594-G8 16-7/8" FINISH: PRIMER
Upper Hex Bolt 13-7/8" WEIGHT: 16.45 LBS / 7.46 Kg
1110-4511
Upper Hex Nut
RETRACTED DECK LEVEL EXTENDED POSITION
PATENT PENDING

904-696-0010
E-mail: sales@buffersusa.com
1101-40 11/30/23
