1109-02
[return to Table of Contents]
RISER BLOCKS & INSERT BUSHING
for TWISTLOCKS
CHASSIS

MODEL 1109-1566
O.D. 3-7/8" RISER BLOCK
Ø98.4 MM Bertolini style
2-1/4" 1-1/8"
57.2 MM 28.6 MM

O.D. 3-1/8"
Ø79.4 MM 1-3/4"
44.5 MM

5/8"
15.9 MM
I.D. 1-7/8"
1109 Ø47.6 MM
I.D. 2-9/16"
Ø65.7 MM SUB FOR: PENZ 21-24
MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 2.05 LBS / 0.93 Kg

MODEL 1109-1567
O.D. 3-7/8" 2-1/4" 1-1/8" RISER BLOCK
Ø98.4 MM 57.2 MM 28.6 MM Strick style

O.D. 3-1/8" 2-7/8"
Ø79.3 MM 73 MM
5/8"
15.9 MM

1-1/8"
I.D. 1-7/8" 28.6 MM
Ø47.6 MM
I.D. 2-15/16" SUB FOR: PENZ 21-25
Ø74.6 MM FITS: PENZ 90-38/KIT-XX DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 3.15 LBS / 1.43 Kg

MODEL 1109-1667
1/4" INSERT BUSHING for
O.D. 3-13/16" 5.5 MM 2-1/4" 3/4" Buffers 3133, 3190 & 3423
Ø96.8 MM 57.2 MM 19 MM Non-Retractable Twistlocks

2-7/8"
2-3/16" 73 MM
55.6 MM
2-3/16"
54.8 MM

I.D. 1-1/2"
Ø38.9 MM
O.D. 1-15/16"
Ø50 MM
FITS: BUFFERS 1101-3133-NR, 1101-3190-NR & 1101-3423-NR NON-RETRACTABLE TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 1.8 LBS / 0.82 Kg
