SAFETY LATCHES

®
for DROP-IN TWISTLOCKS
CHASSIS

1110-4729-G5 Hex Bolt MODEL 1108-9033
1" 3/8"-16 x 3/4", Grade 5
25.4 MM LATCH ASSEMBLY
1108-9033-1A Latch Tab for 1102-1690-L/R
Drop-In Twistlocks
1108-9033-1B
Threaded Sleeve, 3/8"-16
(welded to Latch Tab)
3/16"
5 MM
1108-9033-2 3/4"
Latch 19 MM 3/8"
9.5 MM
1108 NOTE: Kit components are NOT sold separately.
1/8"
max.
Centerline of
Twistlock Pin

1-3/4"
1-3/4" 44.5 MM
Hole for 44.5 MM
Security Seal DETAIL
WORKS WITH: 1102-1690-L/R DROP-IN TWISTLOCKS
See BUI Drawing 9033-INSTALL for detailed FOR USE ON: BOLSTERS w/ up to 3/8" TOP PLATE THICKNESS
installation instructions (contact Sales Team). MATERIAL: STEEL FINISH: ZINC-PLATED WEIGHT: 0.22 LB / 0.1 Kg

®
904-696-0010
E-mail: sales@buffersusa.com
1108-18 3/29/24
