1101-35
[return to Table of Contents]
TWISTLOCKS – EURO TYPE
NON-RETRACTABLE
CHASSIS

MODEL 1101-3541-NR
6-5/16"
160 MM
3-1/8" 3-1/8"
80 MM 80 MM

2-15/16"
75 MM
5-5/16"
135 MM
2-3/8"
60 MM 1101

1-3/16"
30 MM
1-5/16"
33.5 MM 1/2"
12 MM

4-1/8" O.D. 5/8" 3-3/8"
105 MM Ø16 MM 86 MM

5-15/16" 5"
150 MM 127.5 MM

SUB FOR: BLAIR 149/2NR,
EXPLODED VIEW NSN 5325-01-487-5196, & REINKE 217222
FINISH: WELDABLE PRIMER
WEIGHT: 18.8 LBS / 8.53 Kg
1110-4502
DETENT
SPRING
1110-4501 1105-3534-2
DETENT BALL PIN
(2 pcs.)

• Non-handed design; locks to either left or right
• Euro-dimensioned Top & Back Plates
1110-4503
GREASE FITTING • Grease Fitting
1109-3541-1
HOUSING • Cast Steel Housing & Forged Steel Pin
1110-4514
LATCH PIN 1110-4512
FLAT WASHER
1108-3534-18
LATCH 1110-4513-SS
1110-4531-G5 COTTER PIN
HEX BOLT
1110-4511-J
HEX JAM NUT
1107-3133-4
HANDLE

904-696-0010
E-mail: sales@buffersusa.com
1101-35 9/21/22
