3202-03
PUSH-THROUGH CABLE
SECURITY SEALS

CLASS H & I, PER ISO 17712

PUSH-THROUGH CABLE SEAL
• SELF-LOCKING DESIGN THAT ALLOWS FOR SIZE-ADJUSTABLE LOOP.
• SERIAL NUMBER PRINTED ON BODY. C-TPAT & ISO 17712:2013
Compliant
• GALVANIZED, FLEXIBLE CABLE.
• CARGO TAMPERING DISCOURAGED DUE TO CABLE THAT FRAYS WHEN CUT.

A CABLE
3202 BUFFERS 6550 SERIAL NUMBER DIAMETER Ø
012345
B C CABLE LENGTH
BODY CABLE CABLE PULL-APART WEIGHT PCS./
MODEL CLASS MATERIAL DIAMETER Ø LENGTH A B C STRENGTH PER PC. BOX
1/2"
3/32"
12"
3/4"
1-1/16"
METAL
3202-6550 I (green lock) 2.5 MM 305 MM 12 MM 19.5 MM 27.3 MM 290 LBS 0.08 LBS 500
0.04 Kg
130 Kg
A CABLE
SERIAL NUMBER DIAMETER Ø
B

C CABLE LENGTH

BODY CABLE CABLE PULL-APART WEIGHT PCS./
MODEL CLASS MATERIAL DIAMETER Ø LENGTH A B C STRENGTH PER PC. BOX
3202-6560 I PLASTIC 1/16" 12" 5/16" 1-5/16" 1-1/16" 224 LBS 0.03 LBS 1,000
(white lock) 1.6 MM 305 MM 7.5 MM 34 MM 27.5 MM 102 Kg 0.01 Kg

A
CABLE
SERIAL NUMBER DIAMETER Ø
B BUFFERS 6565
012345
C CABLE LENGTH

BODY CABLE CABLE MINIMUM WEIGHT PCS./
MODEL CLASS A B C PULL-APART
MATERIAL DIAMETER Ø LENGTH STRENGTH PER PC. BOX
3202-6565 METAL 9/64" 12" 5/16" 1-1/32" 1-1/32" 2,755 LBS 0.07 LBS
SPECIAL ORDER ONLY H (blue lock) 3.5 MM 305 MM 7.5 MM 26 MM 26 MM 1,250 Kg 0.03 Kg 500
METAL 9/64" 12" 5/16" 1-1/32" 1-1/32" 2,755 LBS 0.07 LBS
3202-6565-RD H (red lock) 3.5 MM 305 MM 7.5 MM 26 MM 26 MM 1,250 Kg 0.03 Kg 500

904-696-0010
E-mail: sales@buffersusa.com
3202-3 12/7/23
