5008-02

LASHING BARS

EYE / HINGED HEAD

5008-7409
RODHEAD
B
84 MM
3-5/16"

54 MM
2-1/8"
105 MM
4-1/8" 28 MM
1-1/8"

79 MM
3-1/8" 49 MM
A 1-15/16"

BUTT-WELDED BUTT-WELDED 21 MM
13/16"
5008

MIN. B.S.
MODEL (M. TON) A B WEIGHT
SPECIAL ORDER ONLY 5008-ELB-C-36-2300 36 22 MM / 7/8" 2,300 MM / 90.6" 9.90 Kg / 21.8 LBS
SPECIAL ORDER ONLY 5008-ELB-C-36-2400 36 22 MM / 7/8" 2,400 MM / 94.5" 10.3 Kg / 22.8 LBS
SPECIAL ORDER ONLY 5008-ELB-C-36-4550 36 22 MM / 7/8" 4,550 MM / 179.1" 17.3 Kg / 38.1 LBS
5008-ELB-C-36-4670 36 22 MM / 7/8" 4,670 MM / 183.9" 17.0 Kg / 37.6 LBS
SPECIAL ORDER ONLY 5008-ELB-C-36-4700 36 22 MM / 7/8" 4,700 MM / 185" 17.1 Kg / 37.7 LBS
5008-ELB-C-42-4500 42 22 MM / 7/8" 4,500 MM / 177.2" 15.9 Kg / 35.0 LBS
5008-LB-10/22-4500
5008-ELB-C-50-2150 50 25 MM / 1" 2,150 MM / 84.6" 11.0 Kg / 24.3 LBS
5008-ELB-C-50-2200 50 25 MM / 1" 2,200 MM / 86.6" 10.9 Kg / 24.0 LBS
5008-ELB-C-50-2260 50 25 MM / 1" 2,260 MM / 89" 11.6 Kg / 25.6 LBS
SPECIAL ORDER ONLY 5008-ELB-C-50-2300 50 25 MM / 1" 2,300 MM / 90.6" 11.6 Kg / 25.9 LBS
SPECIAL ORDER ONLY 5008-ELB-C-50-2330 50 25 MM / 1" 2,330 MM / 91.7" 13.2 Kg / 29.0 LBS
5008-ELB-C-50-2400 50 25 MM / 1" 2,400 MM / 94.5" 14.0 Kg / 30.9 LBS
5008-ELB-C-50-4700 50 25 MM / 1" 4,700 MM / 185" 21.0 Kg / 46.3 LBS
5008-LB-10-4500 50 25 MM / 1" 4,500 MM / 177.2" 19.96 Kg / 44 LBS
SPECIAL ORDER ONLY 5008-LB-10-5029 50 25 MM / 1" 5,029 MM / 198" 23.3 Kg / 51.36 LBS

MATERIAL: STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
CLASS APPROVED
