5007-22

TOGGLE PINS

MODEL 5007-TB-50-TGN
TOGGLE PIN w/ Spring & SS Stop Pin

Fits all M5, M6, M7, Elt 55,
Elt 65 & FLX 5 Turnbuckles.
Supplied w/ Stop Pin loose that is fitted
after the Toggle Pin is inserted into the Jaw.
Ø30 MM Ø56 MM
O.D. 1-3/16" O.D. 2-7/32" Ask for Fitting Instructions.

13 MM 95 MM 12 MM SUB FOR: APM 357416
17/32" 3-3/4" 15/32"
Max. WEIGHT: 1.57 LBS / 0.71 Kg
5 MM
3/16"

MODEL 5007-TB-50-TGN-140
TOGGLE PIN w/ Spring & Loose SS Stop Pin,
Universal, 30mm x 140mm
5007
Generic Type. Fits most wide-Jaw
Turnbuckles such as AMC, MacGregor/
Conver and Peck & Hale.
Ø30 MM Ø56 MM Supplied w/ Stop Pin loose that is fitted
O.D. 1-3/16" O.D. 2-7/32" after the Toggle Pin is inserted into the Jaw.
Ask for Fitting Instructions.
15 MM 125 MM 20 MM
19/32" 4-15/16" 25/32"
Max. WEIGHT: 1.95 LBS / 0.89 Kg
6 MM
1/4"

TOGGLE/CLEVIS PIN MODEL 5007-APM-510-00/7
WASHER MODEL 5007-APM-510-00/10
For APM Turnbuckles & FLX5 (700 to 1195 series) COTTER PIN MODEL 5201-4561-SS
Ø56 MM
115 MM O.D. 2-7/32"
4-17/32"
Ø30.5 MM Ø40 MM Ø32 MM 6 MM
O.D. 1-3/16" O.D. 1-9/16" I.D. 1-1/4" 15/64"
50 MM
96 MM 1-31/32"
3-25/32" 4 MM / 5/32"
CLEVIS PIN 5007-APM-510-00/7 WASHER 5007-APM-510-00/10 COTTER PIN 5201-4561-SS
SUB FOR: APM 317890, 334316 SUB FOR: APM 317891, 334317 SUB FOR: APM 317892
& MACGREGOR 1131343 & MACGREGOR 1131344 & MACGREGOR 1131301
MATERIAL: FORGED STEEL MATERIAL: STAINLESS STEEL MATERIAL: STAINLESS STEEL
FINISH: HOT-DIP GALVANIZED FINISH: SELF-COLOR FINISH: SELF-COLOR
WEIGHT: 1.45 LBS / 0.66 Kg WEIGHT: 0.09 LBS / 0.04 Kg WEIGHT: 0.03 LBS / 0.014 Kg

904-696-0010 FAX: 904-696-0019
E-mail: sales@buffersusa.com
5007-22 11/13/20
