P. 109
5005-06
WELD-DOWN TWISTLOCKS
®
MODEL 5005-C44B-LL
WELD-DOWN TWISTLOCK
Left-locking
145 MM
60 MM 5-11/16"
2-3/8" 116 MM
4-9/16"
87 MM 140 MM
3-7/16" 5-1/2"
143 MM 8.5 MM
5-5/8" 5/16"
160 MM
56 MM 6-5/16"
2-3/16"
137 MM 112 MM 34.8 MM
5-3/8" 4-7/16" 1-3/8" 19 MM
3/4"
5005
MIN. B.L. TENSION: 40 M. TON MIN. B.L. SHEAR: 42 M. TON
ALLSET DRAWING #: 03111
FINISH: HOT-DIP GALVANIZED (HDG)
WEIGHT: 15.87 LBS / 7.2 Kg
MODEL 5005-C44B-RL
WELD-DOWN TWISTLOCK
Right-locking
145 MM
60 MM 116 MM 5-11/16"
2-3/8"
4-9/16"
87 MM 140 MM
3-7/16" 5-1/2"
143 MM 8.5 MM
5-5/8" 5/16"
56 MM 160 MM
2-3/16" 6-5/16"
137 MM 112 MM 34.8 MM
5-3/8" 4-7/16" 1-3/8" 19 MM
3/4"
MIN. B.L. TENSION: 40 M. TON MIN. B.L. SHEAR: 42 M. TON
ALLSET DRAWING #: 03370
FINISH: HOT-DIP GALVANIZED (HDG)
WEIGHT: 15.87 LBS / 7.2 Kg
904-696-0010
E-mail: sales@buffersusa.com
5005-6 8/24/22
