1404-13
[return to Table of Contents]
DOOR GASKET ASSEMBLIES
for 9' 6" x 96" MCIQ
REEFER CONTAINERS

MODEL 1404-6933 MODEL 1404-6934
3-SIDED OUTER DOOR GASKET 4-SIDED OUTER DOOR GASKET

A A

GASKET GASKET
INSIDE HEIGHT B INSIDE HEIGHT A B
DIMENSION DIMENSION 1404

C C

GASKET GASKET
INSIDE WIDTH INSIDE WIDTH
DIMENSION DIMENSION

1-3/8" 1-5/16"
36 MM 1-1/8" 7/8" 1-5/8"
28 MM 33 MM 23 MM 42 MM
1-7/8" 1-3/4"
48.5 MM 44 MM
1-1/2" 1-1/2"
1/2" 37.2 MM 1/2" 37.2 MM 1-3/8" 7/8"
13 MM 1-5/8" 13 MM 1-5/8" 35.5 MM 23 MM
42 MM 42 MM

PROFILE A PROFILE B PROFILE C

MODELS 1404-6933 & 1404-6934
SUB FOR: MAERSK 7813100 FIT: 40' MCIQ REEFER

GASKET GASKET
MODEL DESCRIPTION WEIGHT
INSIDE WIDTH INSIDE HEIGHT
44" FOR
3-SIDED FOR
99" FOR
MODEL 1404-6933 9' 6" CONTAINER 45" WIDTH DOOR 101" HEIGHT DOOR 5.8 LBS
2.6 Kg
99" FOR
44" FOR
4-SIDED FOR
MODEL 1404-6934 9' 6" CONTAINER 45" WIDTH DOOR 101" HEIGHT DOOR 9.3 LBS
4.2 Kg

904-696-0010
E-mail: sales@buffersusa.com
1404-13 6/18/21
