Page 204 - Buffers USA 2024 Container Hardware Catalog FlipBook

1404-12
[return to Table of Contents]
DOOR GASKET ASSEMBLIES
for 8' 6" & 9' 6" x 96"
REEFER CONTAINERS

MODEL 1404-8954-L (8' 6") MODEL 1404-8954-R (8' 6")
MODEL 1404-8955-L (9' 6") MODEL 1404-8955-R (9' 6")
DOOR GASKET, Combo Design Inner & Outer, Left DOOR GASKET, Combo Design Inner & Outer, Right
GASKET GASKET
INSIDE WIDTH INSIDE WIDTH
DIMENSION DIMENSION

A A

1404 GASKET GASKET
INSIDE HEIGHT A B C A INSIDE HEIGHT
DIMENSION DIMENSION

A A

1/8"
3 MM
3/4" 2" 3/4" 2-3/16"
20 MM 51.5 MM 20 MM 55 MM
7/8" 3/8"
22 MM 9 MM
1-3/16" 5/16" 1-3/16"
30.9 MM 8.5 MM 30.9 MM
PROFILE A PROFILE B PROFILE C

MODELS 1404-8954-L/R & 1404-8955-L/R FIT: CIMC 40' REEFER
GASKET GASKET
MODEL DESCRIPTION WEIGHT
INSIDE WIDTH INSIDE HEIGHT
4-SIDED THERMAL
MODEL 1404-8954-L DOOR GASKET (LEFT) 43-1/8" / 1,095.4 MM 85" / 2,159 MM 6.68 LBS
FOR 8' 6" HEIGHT CONTAINERS w/ flat center gasket 3 Kg
SUB FOR: CIMC 06-033-L
4-SIDED THERMAL
MODEL 1404-8954-R DOOR GASKET (RIGHT) 43-1/8" / 1,095.4 MM 85" / 2,159 MM 9 LBS
FOR 8' 6" HEIGHT CONTAINERS SUB FOR: CIMC 06-033-R 4.1 Kg

4-SIDED THERMAL
MODEL 1404-8955-L DOOR GASKET (LEFT) 43-1/8" / 1,095.4 MM 96-5/8" / 2,454.3 MM 7.4 LBS
FOR 9' 6" HEIGHT CONTAINERS SUB FOR: CIMC 06-034-L 3.4 Kg
4-SIDED THERMAL
MODEL 1404-8955-R DOOR GASKET (RIGHT) 43-1/8" / 1,095.4 MM 96-5/8" / 2,454.3 MM 10 LBS
FOR 9' 6" HEIGHT CONTAINERS SUB FOR: CIMC 06-034-R 4.5 Kg

904-696-0010
E-mail: sales@buffersusa.com
1404-12 6/18/21
