ALUMINUM T-FLOOR

REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 1311-6224
ALUMINUM T-FLOOR
2-T, Side

FITS: MCIQ 40' HC REEFER
LENGTH: 36' 9-1/2" / 11,213 MM
MATERIAL: ALUMINUM
FINISH: SELF-COLOR
WEIGHT: 83.16 LBS / 38.5 Kg

1311
1-1/8"
28.6 MM (TYP x 2)

3-13/16"
97.5 MM
2-1/2"
63.5 MM

2-11/16" 2-1/2" 1-1/2"
68.2 MM 63.5 MM 38.2 MM
3-1/16"
78.5 MM
7-1/8"
180.2 MM

MODEL 1311-6434
ALUMINUM T-FLOOR
2-T, Side

SUB FOR: MAERSK 7220236
FITS: MCIQ 40' HC REEFER
LENGTH: 37' 2-1/4" / 11,336 MM
MATERIAL: ALUMINUM
FINISH: SELF-COLOR
WEIGHT: 77.4 LBS / 35.1 Kg
1-1/8"
5/8" 28.6 MM (TYP x 2)
15.5 MM

2-1/2"
63.5 MM

2-1/2" 2-1/2" 1-1/2"
63.5 MM 63.5 MM 38.2 MM
2-3/4"
70.1 MM
