2003-01
[return to Table of Contents]
REAR LIGHT BOX

CHASSIS | TRAILERS: AUTO / FLATBED

MODEL 2003-1983-RS MODEL 2003-1983-CS
ROADSIDE CURBSIDE

3-15/16"
100 MM I.D. 2-1/2" 5-5/8" 7" I.D. 4-9/16"
Ø63.5 MM 142.9 MM 177.8 MM Ø115.9 MM

3-1/4"
6-3/8" 82.55 MM
163 MM I.D. 3/8"
11-3/16" Ø9.5 MM
284 MM
5/8" 1-1/2"
16 MM 38 MM
2003
1"
25.4 MM
3/16" 1-1/2" 7" 7" 7"
4.5 MM 38.1 MM 177.8 MM 177.8 MM 177.8 MM

27-3/4"
704.85 MM

I.D. 1-1/32"
Ø26 MM

2003-1983-RS (ROADSIDE) SHOWN
2003-1983-CS (CURBSIDE) IS THE MIRROR OPPOSITE

SUB FOR: PENZ 70-42-LH/RH, STRICK
MATERIAL: FAB. STEEL
FINISH: BLACK PRIMER
2003-1983-CS WEIGHT: 35.7 LBS / 16.19 Kg
2003-1983-RS WEIGHT: 32.7 LBS / 14.83 Kg

904-696-0010
E-mail: sales@buffersusa.com
2003-1 3/8/19
