TIRE CARRIERS
CHASSIS & TRAILERS:
AUTO / DRY VAN / FLATBED / REEFER VAN
MODEL 2001-7468-PA
UNIVERSAL-STYLE TIRE CARRIER
2-piece Bolted Design, Unassembled, Packaged
28-1/4" in Carton w/ welded Mounting Brackets
48"
21-1/2"
31-1/8"
51-3/16" MATERIAL: FAB. STEEL
FINISH: BLACK PRIMER
WEIGHT: 47.3 LBS / 21.5 Kg
MODEL 2001-7570-PKG
NASH-STYLE TIRE CARRIER
23-15/16" 2-Piece Bolted Design, Unassembled, Packaged
in Buffers Carton; NOTE: Does NOT include
49-7/8" Mounting Bracket Kit*
WARNING 2001
23-7/16" MATERIAL: FAB. STEEL
FINISH: BLACK PRIMER
WEIGHT: 39.5 LBS / 17.9 Kg
32-11/16"
*NOTE: Bolt-on Mounting Bracket Kit (Model 2001-7573-P)
is SOLD SEPARATELY (see below)
MODEL 2001-7573-P
BOLT-ON MOUNTING BRACKET KIT
for Model 2001-7570 Nash-style Tire Carrier
INCLUDES:
Mounting brackets (3 ea.)
Angled Bracket (1 ea.)
FINISH: BLACK PRIMER
AND
Hex Bolts, Self-Locking Nuts & Washers (10 ea.)
FINISH: ZINC-PLATED
Packaged in one plastic bag.
TOTAL WEIGHT: 5.75 LBS / 2.61 Kg
