P. 236
1107-28
[return to Table of Contents]
HANDLES
for TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1107-3248-4 MODEL 1107-3260-4
TWISTLOCK HANDLE TWISTLOCK HANDLE
I.D.
Ø1-1/2"
I.D. 1-1/2"
Ø39 MM
5-3/8"
O.D. 2-1/4"
Ø57 MM 45° 2-3/8"
7-1/2" 60.5 MM
1107
3-3/8"
55º 85.6 MM
5-1/8"
9/16"
3-3/4" 14.5 MM 130 MM
I.D. 1/2" / Ø13 MM O.D. 5/8" / Ø16 MM
1-3/16" 1-1/8"
29 MM
7-1/2" / 190.5 MM
9/16" I.D. Ø1/2" 3/16" O.D. Ø3/4" FITS: BUFFERS 1102-3260-L/R, 1102-3261-L/R
& 1102-3262-L/R DROP-IN TWISTLOCKS
FITS: BUFFERS 1102-3248-L/R & 1102-3257-L/R DROP-IN WORKS WITH: BUFFERS 1105-1257-2, 1105-3259-2,
TWISTLOCKS WORKS WITH: BUFFERS 1105-1257-2 PIN, 1105-3557-2; PENZ 15-69 & WEST LAKE 1780 PINS,
1108-1224-2L/R LATCHES, 1110-4524-G5 HEX BOLT BUFFERS 1110-4524-G5/G8 HEX BOLTS & 1110-4511
& 1110-4511 HEX NUT MATERIAL: FAB. STEEL HEX LOCK NUT MATERIAL: FORGED STEEL
FINISH: ZINC-PLATED WEIGHT: 1.78 LBS FINISH: ZINC-PLATED WEIGHT: 0.75 LB
MODEL 1107-3269-4 MODEL 1107-3270-4
TWISTLOCK HANDLE TWISTLOCK HANDLE
SPECIAL ORDER
8-13/16"
I.D. 1-1/2"
Ø39 MM
1-1/8"
1-15/16"
45° 2-3/16"
55.2 MM 4-1/4" 4-5/16"
O.D. 2-1/4"
Ø57 MM 1-15/16"
49.6 MM
I.D. Ø1/4"
4-13/16"
122.6 MM
7" / 177.8 MM O.D. Ø5/8"
9/16" I.D. 1/2" O.D. 3/4"
14.5 MM Ø13 MM Ø19 MM
1-1/8"
29 MM
FITS: BUFFERS 1102-1236-L/R &
1102-3270-LH/RH DROP-IN TWISTLOCKS
FITS: BUFFERS 1102-3269-L/R DROP-IN TWISTLOCKS WORKS WITH: BUFFERS 1105-1148-2;
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED PENZ 15-160, 15-162-C PINS MATERIAL: FAB. STEEL
WEIGHT: 1.5 LBS / 0.68 Kg FINISH: ZINC-PLATED WEIGHT: 0.95 LB
904-696-0010
E-mail: sales@buffersusa.com
1107-28 10/25/23
