MUD FLAP BRACKETS
CHASSIS & TRAILERS:
AUTO / DRY VAN / FLATBED / REEFER VAN

MODEL 2002-6498
BOLTING PLATE
SUB FOR: PENZ 07-51
MATERIAL: FAB. STEEL
FINISH: PRIMER
1-1/2" 7" 7" 7" Ø7/16" x 4 HOLES WEIGHT: 6.3 LBS / 2.86 Kg

1"
4-15/16" MUD FLAP
NOT INCLUDED

23-15/16" 3/16"

MODEL 2002-6519
BOLTING PLATE
Conical Angle

SUB FOR:
1/8"
TRAILMOBILE 1-700-522-45,
FRUEHAUF FCF 6215-1
MATERIAL: FAB. STEEL
FINISH: PRIMER
WEIGHT: 6.85 LBS / 3.11 Kg
1-9/16"
13/16" 5-3/4" 6-7/16" 5-3/4" 1-1/2"
1"
2-3/4" 1/4" 2002
1/4" x 4 HOLES 1-3/4" x 4 SLOTS 3-1/2" MUD FLAP
NOT INCLUDED
26-13/16"

MODEL 2002-6536-RS
MODEL 2002-6536-CS
ANGLED BOLTING PLATE
ROADSIDE CURBSIDE

SUB FOR: TRAILMOBILE
6" 1" 522-5-236LH (-RS) &
522-5-236RH (-CS)
MATERIAL: FAB. STEEL
FINISH: PRIMER
Ø11/16" x 2 HOLES WEIGHT: 9.15 LBS / 4.15 Kg
1-1/2"
7" 7" 7"
Ø5/16" x 8 HOLES 2"
3/4"
3" MUD FLAP

1-1/2" NOT INCLUDED
32-3/4"
3/16"
