STAINLESS STEEL FLAT SHEETS

REEFER CONTAINERS | REEFER VAN TRAILERS

STAINLESS STEEL FLAT SHEETS
MODEL WIDTH LENGTH THICKNESS WEIGHT
108"
48"
SPECIAL ORDER MODEL 1211-6992 1,219 MM 2,743 MM 18 GA. / 0.048" 70.12 LBS
1.22 MM
31.81 Kg
108"
48"
SPECIAL ORDER MODEL 1211-6993-409 1,219 MM 2,743 MM 20 GA. / 0.036" 52.6 LBS
0.914 MM
23.86 Kg
120"
48"
MODEL 1211-6994-304 1,219 MM 3,048 MM 22 GA. / 0.029" 48.57 LBS
0.76 MM
22.03 Kg
48"
120"
MODEL 1211-6995-409 1,219 MM 3,048 MM 20 GA. / 0.036" 58.43 LBS
26.5 Kg
0.914 MM
120"
48"
SPECIAL ORDER MODEL 1211-6995-304-PVC * 1,219 MM 3,048 MM 20 GA. / 0.036" 59.64 LBS
0.914 MM
27.05 Kg
78 LBS
120"
48"
SPECIAL ORDER MODEL 1211-6996 1,219 MM 3,048 MM 18 GA. / 0.048" 35.38 Kg
1.22 MM
1211
48"
120"
SPECIAL ORDER MODEL 1211-6997 1,219 MM 3,048 MM 16 GA. / 0.059" 97.06 LBS
1.52 MM
44.03 Kg
MATERIAL: STAINLESS STEEL, except:
*6995-304-PVC MATERIAL: GRADE 304SS w/ PVC PROTECTION
FINISH: SELF-COLOR
MODEL 1403-7704
EXTERNAL FLAT DOOR SHEET (SKIN) FOR REEFERS
LENGTH: 97-7/8" WIDTH: 42-3/16" THICKNESS: 1/16" / 1.6 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
WEIGHT: 72.8 LBS / 33.02 Kg
