1107-11
[return to Table of Contents]
HANDLES
for PINLOCKS
CHASSIS | FLATBED TRAILERS

PINLOCK HANDLE MODEL 1107-1417-4
PIN MODEL 1106-1417-2
HANDLE
MODEL 1107-1417-4 PIN MODEL 1106-1617-2
4-3/4" 4-3/4"
PIN PIN
MODEL 1106-1417-2 MODEL
1106-1617-2
1417-2
LH CONFIGURATION
O.D. Roadside 1107
O.D. Ø5/8" O.D.
Ø1-1/2" Ø1-1/2" 1417-2
RH CONFIGURATION
Curbside
3-1/4" 1"
5-1/2"
6-15/16"
THESE PARTS ARE SOLD SEPARATELY. 1617-2
Pin & Handle must be welded together after installation. LH CONFIGURATION
Roadside
SUB 1107-1417-4 HANDLE FOR: PENZ 20-111 1617-2
SUB 1106-1417-2 PIN FOR: PENZ 30-28 & 30-28/CR SUB 1106-1617-2 PIN FOR: PENZ 30-30 RH CONFIGURATION
HANDLE FITS: BUFFERS 1103-1417, 1103-1617 & PENZ 90-19/H-XX PINLOCKS Curbside
1106-1417-2 PIN FITS: BUFFERS 1103-1417-L/R, PENZ 90-20-XX & 90-20/CR-XX PINLOCKS
1106-1617-2 PIN FITS: BUFFERS 1103-1617-L/R, PENZ 90-19-XX & 90-19/H-XX PINLOCKS
MATERIAL: FAB. STEEL FINISH: PRIMER 1107-1417-4 HANDLE WEIGHT: 0.6 LBS
1106-1417-2 PIN WEIGHT: 2.4 LBS 1106-1617-2 PIN WEIGHT: 2 LBS

MODEL 1107-1464 1/2" MODEL 1107-1469
PINLOCK HANDLE PINLOCK HANDLE

Supplied w/
Pin welded on
3-7/16"
I.D.
Ø3/8"
6-13/16"
1-9/32"

2" REF
7-3/8" O.D. Ø1-1/2"
I.D.
7/8" Ø11/16" I.D. Ø13/32" 2-7/8" 1" I.D. Ø13/32" x 2 HOLES
1-1/4" 1-1/2"

13/32" 5-7/16"
5/8" 7-7/8"
12"
SUB FOR: PENZ 20-84HDC
FITS: BUFFERS 1103-1624-L/R, PENZ 90-14HDC-XX
SUB FOR: PENZ 20-56 FITS: PENZ 90-01-XX & SCHULZ FB88HL-XX PINLOCKS
& SCHULZ FB55HL-XX PINLOCKS WORKS WITH: BUFFERS 1108-1350 LATCH &
MATERIAL: CAST STEEL FINISH: PRIMER 1110-4537 SPLIT ROLL PIN MATERIAL: FAB. STEEL
WEIGHT: 2.05 LBS FINISH: PRIMER WEIGHT: 4.55 LBS

904-696-0010
E-mail: sales@buffersusa.com
1107-11 12/10/20
