1107-05
[return to Table of Contents]
HANDLES

for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1107-1300-L
MODEL 1107-1300-R
TWISTLOCK HANDLES
4-3/4"
I.D. Ø1-1/2"

3-7/8"
1107
MODEL 1300-L MODEL 1300-R

5-5/8"
I.D.
Ø1/2"
I.D. 1-7/16"
Ø1/4"
2"

O.D. Ø5/8"
SUB FOR: PENZ 20-113-XX, WEST LAKE 1222-L/R FITS: WEST LAKE ML85-4 & ML85-5 TWISTLOCKS
WORKS WITH: BUFFERS 1105-1321 PIN & 1108-1271 LATCH
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED WEIGHT: 1.6 LBS

THESE PARTS ARE MODEL 1107-1341 MODEL 1107-1344
SOLD SEPARATELY. PINLOCK HANDLE TWISTLOCK HANDLE
MODEL 1107-1344-KIT
SPLIT ROLL PIN
MODEL 1110-4599 INCLUDES:
1110-4511 Nut &
1110-4529-G8 Bolt
O.D.
Ø5/8"
PIN
MODEL 1106-1340
I.D. 3-1/16" 1-15/16"
Ø1-9/16" I.D.
O.D. Ø3/16" Ø9/16"
1-1/2" O.D.
5-15/16" Ø1-1/2"
I.D. I.D. Ø5/8" I.D.
Ø3/16" Ø7/16" 3-3/8"

1" 5-13/16" 15/16"
1-3/16" 7-1/8" 1-1/4"
SUB FOR: PENZ 20-55 FITS: BUFFERS 1101-3606-L/R,
HANDLE SUB FOR: PENZ 20-99-2, WEST LAKE 1306 1101-3606-LP-L/R, 1101-3706-L/R, 1101-3707-L/R; PENZ 90-05-XX,
FITS: WEST LAKE ML90-2/3 PINLOCK 90-05/A-XX, 90-06-XX; SCHULZ F33NS Series TWISTLOCKS
WORKS WITH: BUFFERS 1105-1447, 1105-1452, 1105-7339
WORKS WITH (shown above): BUFFERS 1106-1340 PIN, & 1105-7470 PINS, 1108-1345 LATCH, 1110-4529-G8 HEX BOLT &
1110-4599 SPLIT ROLL PIN MATERIAL: FAB. STEEL 1110-4511 HEX LOCK NUT HANDLE MATERIAL: CAST STEEL
HANDLE FINISH: ZINC-PLATED PIN FINISH: PRIMER HANDLE FINISH: PRIMER HANDLE WEIGHT: 2.87 LBS
HANDLE WEIGHT: 0.45 LBS PIN WEIGHT: 3.1 LBS KIT WEIGHT: 3.15 LBS

904-696-0010

E-mail: sales@buffersusa.com
1107-5 10/25/23
