P. 136
5007-02
EQUALASH COMPARISON
®
PARALLEL LASHING VS. EQUALASH SYSTEM
PARALLEL LASHING SYSTEM EQUALASH SYSTEM
2 x Ø25 MM BARS
2 x Ø22 MM BARS
5007
MIN. B.L. FOR EACH LASHING = 50 TON MIN. B.L. FOR EACH LASHING = 42 TON
MIN. B.L. FOR SYSTEM = 75 TON MIN. B.L. FOR SYSTEM = 84 TON
Ø25 MM Ø25 MM Ø22 MM Ø22 MM
100% EFFECTIVE 100% EFFECTIVE
CROSS-SECTION AREA CROSS-SECTION AREA
FOR BREAK LOAD FOR BREAK LOAD
& ELASTICITY. & ELASTICITY.
TOTAL EFFECTIVE CROSS-SECTION AREA = 736 MM 2 TOTAL EFFECTIVE CROSS-SECTION AREA = 760 MM 2
EQUALASH GIVES THE ADVANTAGE OF PARALLEL LASHING (NO LONG RODS) WITH ONLY HALF THE QUANTITY
OF TURNBUCKLES AND THINNER RODS – COMPARED WITH PARALASH (Ø22 MM INSTEAD OF Ø25 MM) –
AND STILL MAINTAINING THE SAME STACK WEIGHTS.
CONTACT US FOR MORE INFORMATION.
®
