Page 64 - Buffers USA 2024 Container Hardware Catalog FlipBook

1207-04
[return to Table of Contents]
STRUCTURAL STEEL SHAPES
CHASSIS | CONTAINERS: DOMCON / FLATRACK / ISO
& TRAILERS: AUTO / DRY VAN / FLATBED

FLAT BAR

A MATERIAL: HRS
STEEL: SELF-COLOR
B
1207
MODEL A B LENGTH WEIGHT
SPECIAL ORDER 1207-6183-9-5/8 1/2" 3/4" 9-5/8" / 244.5 MM 0.95 LBS / 0.43 Kg
SPECIAL ORDER 1207-6183 1/2" 3/4" 20' / 6,096 MM 25 LBS / 11.3 Kg
SPECIAL ORDER 1207-6158 3/16" 2" 20' / 6,096 MM 25 LBS / 11.3 Kg
SPECIAL ORDER 1207-6159 1/4" 2" 20' / 6,096 MM 34 LBS / 15.4 Kg
SPECIAL ORDER 1207-6161 5/8" 2" 20' / 6,096 MM 85 LBS / 38.6 Kg
1208-6162 1/2" 2-1/2" 20' / 6,096 MM 85 LBS / 38.6 Kg
SPECIAL ORDER 1207-6163 1/4" 3" 20' / 6,096 MM 50 LBS / 22.7 Kg
SPECIAL ORDER 1207-6164 3/16" 4" 20' / 6,096 MM 50 LBS / 22.7 Kg
SPECIAL ORDER 1207-6165 1/8" 8" 20' / 6,096 MM 68 LBS / 30.8 Kg
SPECIAL ORDER 1207-6166 3/16" 8" 20' / 6,096 MM 100 LBS / 45.4 Kg
SPECIAL ORDER 1207-6167 1/4" 8" 20' / 6,096 MM 135.8 LBS / 61.6 Kg

PLATE STEEL

A B

C

MODEL A B C WEIGHT MATERIAL / FINISH
SPECIAL ORDER 1207-6125 1/8" 24" 24" 19.8 LBS / 9 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6126 1/8" 96" 48" 159.2 LBS / 72.2 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6176 3/16" 72" 11" 40.8 LBS / 18.5 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6177 3/16" 96" 48" 238.2 LBS / 108 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6178 3/16" 98" 48" 249.9 LBS / 113.4 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6179 3/16" 120" 48" 306 LBS / 138.8 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6180 1/4" 22-1/2" 7" 11.2 LBS / 5.1 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-6181 1/4" 76" 12-1/2" 70 LBS / 31.8 Kg CORTEN / PRIMER
SPECIAL ORDER 1207-6182 1/4" 96" 48" 339.5 LBS / 154 Kg HRS / SELF-COLOR
SPECIAL ORDER 1207-8835 1-1/4" 80" 76" 2,155.45 LBS / 977.7 Kg HRS / SELF-COLOR

904-696-0010
E-mail: sales@buffersusa.com
1207-4 3/5/21
