1205-20
[return to Table of Contents]
INTERMEDIATE STACKING POSTS
INNER & OUTER
DOMCON CONTAINERS

SPECIAL ORDER ONLY MODEL 1205-7140
INTERMEDIATE STACKING POST
Outer

1205 7-5/16" 8-9/16"
186 MM 217 MM
2-1/8"
54.5 MM

3/16"
12-3/16" 8-1/16" 1-13/16" 4.5 MM
46 MM
310 MM 204 MM
2-1/8"
54.5 MM

107"
2,718 MM

SUB FOR: SINGAMAS FM53-303003 FITS: FERROMEX, SINGAMAS 53'
MATERIAL: HIGH-STRENGTH STEEL FINISH: PRIMER
LENGTH: 107" / 2,718 MM WEIGHT: 60.9 LBS / 27.62 Kg

MODEL 1205-7141
SPECIAL ORDER ONLY
INTERMEDIATE STACKING POST
Inner, C-channel

I.D. 9/16" 1-3/8"
Ø14 MM x 4 holes 35 MM
4-3/4"
120 MM
1-9/16" 2-9/16"
40 MM 65 MM
3/6"
4.5 MM
1/4"
R6 MM 1-3/8"
35 MM
7-15/16" 1/8" / 3 MM x 45°
201 MM 2 places
103-11/16"
2,634 MM

SUB FOR: SINGAMAS FM53-303004 FITS: FERROMEX, SINGAMAS 53'
MATERIAL: HIGH-STRENGTH STEEL FINISH: WELDABLE GRAY PRIMER
LENGTH: 103-11/16" / 2,634 MM WEIGHT: 51.85 LBS / 23.13 Kg

904-696-0010
E-mail: sales@buffersusa.com
1205-20 1/30/24
