6202-01
[return to Table of Contents]
CORNER CASTINGS
FOR 102" WIDE
DOMCON CONTAINERS

CASTING CONFIGURATION

6202-1908-I
TOP LEFT 6202-1905-E
TOP INTERMEDIATE
(non-handed)
6202-1909-J 6202-1905-E
TOP RIGHT TOP INTERMEDIATE
6202-1905-E (non-handed) 6202-1909-J
TOP INTERMEDIATE TOP RIGHT
(non-handed)
6202-1905-E
TOP INTERMEDIATE 6202-1908-I
(non-handed)
TOP LEFT

6202-1901-A
BOTTOM LEFT 6202-1903-C
BOTTOM LEFT
INTERMEDIATE
6202-1902-B
BOTTOM RIGHT 6202-1904-D 6202-1904-D
BOTTOM RIGHT
BOTTOM RIGHT INTERMEDIATE 6202-1907-G
INTERMEDIATE BOTTOM RIGHT
DOOR SEAL
ALL CORNER FITTINGS: 6202-1903-C
BOTTOM LEFT 6202-1906-F
MATERIAL: CAST STEEL INTERMEDIATE BOTTOM LEFT
FINISH: SELF-COLOR DOOR SEAL

MODEL 6202-1901-A MODEL 6202-1903-C SPECIAL ORDER ONLY
BOTTOM LEFT MODEL 6202-1902-B BOTTOM LEFT MODEL 6202-1904-D
INTERMEDIATE
BOTTOM RIGHT BOTTOM RIGHT
INTERMEDIATE

4-5/8"
TOP VIEW 118 MM TOP VIEW
1-5/16"
2" 3-1/8" 2" 2" 33.5 MM 4-5/8"
51 MM 79.5 MM 51 MM 51 MM 118 MM
3-1/8"
79.5 MM
3-1/2"
SIDE VIEW 4" / 101.5 MM 6-1/2" SIDE VIEW 89 MM 3-1/16" SIDE VIEW
7" / 178 MM 165 MM 7" / 178 MM 78 MM
6202 SIDE VIEW
I.D. 4-7/8"
I.D. 4-7/8" 6-1/2" 6-1/2" 9-3/16"
Ø124 MM 165 MM 9-3/16" Ø124 MM 165 MM 8" 234 MM
2-1/2" 234 MM 2-1/2" 203 MM
63.5 MM 63.5 MM
3-1/2"
4" / 101.5 MM WEIGHT: WEIGHT: 89 MM 1/2" 15/16"
24.5 MM
12.5 MM
BOTTOM VIEW 33.47 LBS / 15.18 Kg 32.95 LBS / 14.95 Kg BOTTOM VIEW
MODEL 6202-1901-A Bottom Left Casting is shown dimensioned; MODEL 6202-1903-C Bottom Left Casting is shown dimensioned;
MODEL 6202-1902-B Bottom Right Casting is the mirror opposite. MODEL 6202-1904-D Bottom Right Casting is the mirror opposite.

904-696-0010
E-mail: sales@buffersusa.com
6202-1 12/27/21
