4406-05
[return to Table of Contents]
DRAIN PARTS
PLUG & VALVE ASSEMBLIES
REEFER CONTAINERS | REEFER VAN TRAILERS

MODEL 4406-1981-KIT O.D. 1-23/32" MODEL 4406-6948
MODEL 4406-1982-KIT Ø43.8 MM DRAIN VALVE ASSEMBLY
REEFER DRAIN PLUG ASSEMBLIES

1/8"
3.2 MM
MODEL 1981-KIT MODEL 1982-KIT
O.D. 1-5/8"
O.D. 1-5/16" Ø41.3 MM
Ø33.34 MM
2-21/32"
67.8 MM
7/8" 1" 1-1/4" Drain Valve
22.23 MM 25.4 MM
3-19/32"
91 MM
O.D. 1-1/16" O.D. 1-3/8"
Ø27 MM Ø34.9 MM
WEIGHT: 0.1 LBS WEIGHT: 0.15 LBS 1-3/16"
(includes Lanyard) (includes Lanyard) 30 MM
1-17/32"
38.6 MM

BOTH PLUGS HAVE APPROX. 8" MATERIAL: BLACK RUBBER & PVC
STAINLESS STEEL LANYARD ATTACHED WEIGHT: 0.13 LBS / 0.06 Kg

O.D. 2" MODEL 4406-6949 MODEL 4406-7529
Ø51 MM
DRAIN VALVE ASSEMBLY AUTOMATIC DRAIN
VALVE ASSEMBLY
Stainless Steel
Chain attached
4406 O.D. 1-1/2"
Ø38.5 MM
1-17/32" 1/8"
39.1 MM 3.2 MM

2-29/32" Float Ball included
73.7 MM
1-1/32"
25.8 MM
1-5/8" Drain Valve
3-5/8"
92.4 MM
O.D. 1-3/8"
Ø35 MM
1-3/16"
30 MM
O.D. 1-3/4"
Ø44.5 MM

MATERIAL: BLACK RUBBER & PVC MATERIAL: PE
WEIGHT: 0.16 LBS / 0.07 Kg WEIGHT: 0.06 LBS / 0.03 Kg
