Page 291 - Buffers USA 2024 Container Hardware Catalog FlipBook

4406-08
[return to Table of Contents]
GENERATOR SET BRACKETS

REEFER CONTAINERS

MODEL 4406-6446 MODEL 4406-7230
GENERATOR SET BRACKET GENERATOR SET BRACKET
for Top Header

4 x 45°
TYP.

5-1/2" 5-7/8" 3/16"
139 MM 150 MM 4.5 MM
I.D. 2-3/16" 1/4" I.D. 2-1/4" 2-7/16"
Ø55 MM 6 MM Ø58 MM 62.5 MM
4-3/4" 9/16"
120 MM 15 MM
2-3/8" 2-3/16" 2-3/16"
60 MM 55 MM 55.5 MM
1-3/8"
4-3/4" 35 MM
120 MM 2-11/16" 3-1/8" 1-3/4"
68 MM 80 MM 45 MM

SUB FOR: MAERSK 7133055 FITS: MCIQ 40' REEFER FITS: CIMC & MAERSK MCIQ REEFER
MATERIAL: CORTEN STEEL FINISH: PRIMER MATERIAL: CORTEN STEEL FINISH: PRIMER
WEIGHT: 2.79 LBS / 1.27 Kg WEIGHT: 1.87 LBS / 0.85 Kg

4406

904-696-0010
E-mail: sales@buffersusa.com
4406-8 12/7/23
