Page 270 - Buffers USA 2024 Container Hardware Catalog FlipBook

2909-04
[return to Table of Contents]
EYELET CLIP
FOR REEFER T-FLOOR
REEFER CONTAINERS & REEFER VAN TRAILERS

MODEL 2909-8685

2-1/2"
62.9 MM

2-1/2"
62.9 MM
I.D.1-3/16"
Ø30 MM

60º TEST 2-7/16"
DIRECTION 62 MM
MBS 2,325 LBS USED AS TEMPORARY
1,054.6 Kg TIE-OFF POINT ON REEFER
CONTAINER FLOORS.
MBS 2,325 LBS / 1,054 Kg

WORKS WITH: T-FLOOR MATERIAL: FORGED EYE NUT
FINISH: ZINC-PLATED WEIGHT: 1.05 LBS / 0.48 Kg
2909

904-696-0010
E-mail: sales@buffersusa.com
2909-4 6/18/18
