Page 116 - Buffers USA 2024 Container Hardware Catalog FlipBook

1304-0306-01
13 1310-01
[return to Table of Contents]
FLAT SHEETS & SIDE PANELS
TYPE 3004-H291 ALUMINUM
DRY & REEFER VAN TRAILERS

FINISH COLORS OUTSIDE
MODEL # WIDTH x LENGTH THICKNESS (MILL FINISH INSIDE)
1306-2305-040-PPW 49" x 97" 0.040" (1.016 MM) 18 GA. PAINTED POLAR WHITE
1306-2305-050-PPW 49" x 97" 0.050" (1.270 MM) 16 GA. PAINTED POLAR WHITE
1306-2305-054-PPW 49" x 97" 0.054" (1.372 MM) 15 GA. PAINTED POLAR WHITE
1306-2305-040-TB 49" x 97" 0.040" (1.016 MM) 18 GA. TRAILER BRITE
1306-2305-050-TB 49" x 97" 0.050" (1.270 MM) 16 GA. TRAILER BRITE
1306 1306-2305-054-TB 49" x 97" 0.054" (1.372 MM) 15 GA. TRAILER BRITE
1306-2305-063-TB 49" x 97" 0.063" (1.600 MM) 14 GA. TRAILER BRITE
1306-2305-040-PG 49" x 97" 0.040" (1.016 MM) 18 GA. PAINTED GRAY
1306-2305-050-PG 49" x 97" 0.050" (1.270 MM) 16 GA. PAINTED GRAY
1306-2305-054-PG 49" x 97" 0.054" (1.372 MM) 15 GA. PAINTED GRAY
1306-2305-063-PG 49" x 97" 0.063" (1.600 MM) 14 GA. PAINTED GRAY
1306-2305-040-PB 49" x 97" 0.040" (1.016 MM) 18 GA. PAINTED BLUE
1306-2305-050-PB 49" x 97" 0.050" (1.270 MM) 16 GA. PAINTED BLUE
1306-2305-054-PB 49" x 97" 0.054" (1.372 MM) 15 GA. PAINTED BLUE
1306-2305-063-PB 49" x 97" 0.063" (1.600 MM) 14 GA. PAINTED BLUE
1306-2306-063-PPW 49" x 110" 0.063" (1.600 MM) 14 GA. PAINTED POLAR WHITE
1306-2306-040-TB 49" x 110" 0.040" (1.016 MM) 18 GA. TRAILER BRITE
1306-2306-050-TB 49" x 110" 0.050" (1.270 MM) 16 GA. TRAILER BRITE
1306-2306-054-TB 49" x 110" 0.054" (1.372 MM) 15 GA. TRAILER BRITE
1306-2306-063-TB 49" x 110" 0.063" (1.600 MM) 14 GA. TRAILER BRITE
1306-2306-040-PG 49" x 110" 0.040" (1.016 MM) 18 GA. PAINTED GRAY
1306-2306-054-PG 49" x 110" 0.054" (1.372 MM) 15 GA. PAINTED GRAY
1306-2306-063-PG 49" x 110" 0.063" (1.600 MM) 14 GA. PAINTED GRAY
1306-2306-040-PB 49" x 110" 0.040" (1.016 MM) 18 GA. PAINTED BLUE
1306-2306-050-PB 49" x 110" 0.050" (1.270 MM) 16 GA. PAINTED BLUE
1306-2306-054-PB 49" x 110" 0.054" (1.372 MM) 15 GA. PAINTED BLUE
1306-2306-063-PB 49" x 110" 0.063" (1.600 MM) 14 GA. PAINTED BLUE
1306-2307-040-PPW 49" x 120" 0.040" (1.016 MM) 18 GA. PAINTED POLAR WHITE
1306-2307-054-PPW 49" x 120" 0.054" (1.372 MM) 15 GA. PAINTED POLAR WHITE
1306-2307-040-TB 49" x 120" 0.040" (1.016 MM) 18 GA. TRAILER BRITE
1306-2307-050-TB 49" x 120" 0.050" (1.270 MM) 16 GA. TRAILER BRITE
1306-2307-054-TB 49" x 120" 0.054" (1.372 MM) 15 GA. TRAILER BRITE
1306-2307-063-TB 49" x 120" 0.063" (1.600 MM) 14 GA. TRAILER BRITE
1306-2307-040-PG 49" x 120" 0.040" (1.016 MM) 18 GA. PAINTED GRAY
1306-2307-050-PG 49" x 120" 0.050" (1.270 MM) 16 GA. PAINTED GRAY
1306-2307-054-PG 49" x 120" 0.054" (1.372 MM) 15 GA. PAINTED GRAY
1306-2307-063-PG 49" x 120" 0.063" (1.600 MM) 14 GA. PAINTED GRAY
1306-2307-040-PB 49" x 120" 0.040" (1.016 MM) 18 GA. PAINTED BLUE
1306-2307-050-PB 49" x 120" 0.050" (1.270 MM) 16 GA. PAINTED BLUE
1306-2307-054-PB 49" x 120" 0.054" (1.372 MM) 15 GA. PAINTED BLUE
1306-2307-063-PB 49" x 120" 0.063" (1.600 MM) 14 GA. PAINTED BLUE

OTHER SIZES AVAILABLE UPON REQUEST

904-696-0010
E-mail: sales@buffersusa.com
1306-1 12/6/23
