1101-21
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE

NON-RETRACTABLE w/ LIGHT HOLES
CHASSIS

MODEL 1101-1207-L MODEL 1101-1207-75-L MODEL 1101-1207-275-L
MODEL 1101-1207-R MODEL 1101-1207-75-R MODEL 1101-1207-275-R

I.D. I.D. I.D. I.D. I.D. I.D.
2-5/16" 2-5/16" 2-5/16" 3/4" 2-3/4" 2-3/4"
Ø59 MM Ø59 MM Ø59 MM Ø19.1 Ø69.9 Ø69.9
MM MM MM
1101-1207-L 1101-1207-R 1101-1207-75-L 1101-1207-75-R 1101-1207-275-L 1101-1207-275-R 1101
for Rear Roadside for Rear Curbside for Rear Roadside for Rear Curbside for Rear Roadside for Rear Curbside
(& Front Curbside if 20') (& Front Roadside if 20') (& Front Curbside if 20') (& Front Roadside if 20') (& Front Curbside if 20') (& Front Roadside if 20')
2 Light Holes 1 Light Hole 2 Light Holes 1 Light Hole 2 Light Holes 1 Light Hole
FINISH: WELDABLE PRIMER FINISH: WELDABLE PRIMER FINISH: WELDABLE PRIMER
WEIGHT: 22.3 LBS / 10.1 Kg WEIGHT: 22.5 LBS / 10.2 Kg WEIGHT: 22 LBS / 10 Kg
1-3/16"
7" 30 MM
178 MM 1-1/4"
2"
32 MM 50.8 MM
3-3/4"
95 MM
2-1/4"
7-1/4" 1/2" 56.5 MM
184 MM I.D. 2-5/16" 12 MM
Ø59 MM 4-3/16"
3-1/2" 107 MM I.D. 2-5/16"
5-9/16"
89 MM 140.5 MM Ø59 MM
45º
3-1/2" 3-1/2"
89 MM 89 MM
O.D. 5/8" / Ø16 MM • Cast steel Housing & forged steel Pin
MODEL 1101-1207-L is shown dimensioned. • Meets AAR specifications for Rail use
MODEL 1101-1207-R is the mirror opposite (w/ only one light hole). • Easy-to-operate Gravity Latch
• Angled corner for Side & Rear Light visibility
EXPLODED VIEW 1105-1131-2 • Unused Light Holes can be blanked off with Plugs
PIN shown below, or others shown on pg. 1110-5
1110-4501
DETENT BALL MODEL 1110-8400
(2 pcs.)
1110-4502 8400 shown MODEL 1110-8400-MOD
DETENT SPRING dimensioned LIGHT HOLE PLUG, Weld-on
I.D. 3/4"
1110-4503 Ø19 MM
GREASE FITTING
1109-1207-1-L
HOUSING*
*1105-1131-29 O.D. 2-5/8" 8400 converts 8400-MOD
PIN SLEEVE Ø66 MM 3/8" Ø2-5/16" Light eliminates
is welded to Housing 9 MM Hole to Ø3/4" Light Hole
1110-4632 MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
HEX NUT w/ Nylon Insert 8400 WEIGHT: 0.3 LBS / 0.136 Kg
1110-3706-19L 8400-MOD WEIGHT: 0.33 LBS / 0.15 Kg
LATCH SPRING
for 1101-1207-R Twistlock MODEL 1110-8674
1110-3706-19R I.D. 3/16" LIGHT HOLE PLUG
Ø4.8 MM
LATCH SPRING x 3 HOLES
for 1101-1207-L Twistlock Bolt-on
1110-4631-G5 HEX BOLT
1108-1207-18 LATCH
I.D. 3/4"
1110-4504-G5 HEX BOLT Ø19 MM
O.D. 3-1/8" 1/8" Converts Ø2-5/16"
1107-1207-4 HANDLE Ø79.4 MM 3.5 MM Light Hole to Ø3/4"
1110-4505
HEX NUT w/ Nylon Insert MATERIAL: STEEL FINISH: WELDABLE PRIMER
WEIGHT: 0.28 LBS / 0.127 Kg
904-696-0010
