1501-04
[return to Table of Contents]
SLIDER PINS

CHASSIS & TRAILERS: AUTO / DRY VAN / FLATBED

1/2" 1/4" MODEL 1501-6381
13 MM 6 MM
SLIDER PIN w/ V-Bracket
1-3/8"
35 MM

5-11/16" 1-11/16"
144.5 MM 43 MM

I.D. 1/2"
Ø13 MM x 2 HOLES
SUB FOR: GREAT DANE 13141-13119
PIN MATERIAL: HIGH-STRENGTH STEEL
V-BRACKET MATERIAL: FAB. CARBON STEEL
FINISH: ANTI-GALL / LIGHTLY OILED
O.D. 1-1/2" 2-3/16" I.D. 1/4" 1-1/2" WEIGHT: 3.15 LBS / 1.43 Kg
Ø38 MM 55.6 MM Ø6.35 MM 38 MM

1501
MODEL 1501-6970
SLIDER BOLT
w/ Washers
& Cotter Pin

Ø2"
SHIPPED AS SHOWN
w/ LOOSE COTTER PIN.

5-1/2" FITS: JINDO 48' & 53' SLIDER CHASSIS
MATERIAL: FAB. STEEL / NYLON
6-3/4" FINISH: BLACK PRIMER / SELF-COLOR NYLON
WEIGHT: 8.3 LBS / 3.76 Kg

MODEL 1501-7359
SLIDER PIN w/ Jaw
Ø1/4"

4-1/4"
Ø3/8" 3/8"
x 2 HOLES

3/4" Ø2"
SUB FOR: PENZ 35-12
1-1/4" 1/4" 1/4" MATERIAL: FORGED STEEL
FINISH: BLACK PRIMER
10"
1-3/4" WEIGHT: 8.85 LBS / 4 Kg

904-696-0010
E-mail: sales@buffersusa.com
1501-4 9/24/19
